1-794040-1

Headers, Male Pins Overview

The 1-794040-1 is a board-to-cable or wire header connector from the TE Connectivity AMP Connectors line. It features a through-hole termination style with a shrouded four-wall envelope design. The connector provides 12 positions arranged in a single row, utilizing a 0.163-inch (4.14mm) pitch. It is rated for 600VAC and employs solder termination for secure PCB mounting.

Headers, Male Pins Feature Summary

• Shrouded four-wall housing design for enhanced alignment and protection
• Through-hole solder termination for robust PCB attachment
• Single-row configuration accommodating 12 contact positions

Headers, Male Pins Applications

• Board-to-cable interconnections
• Board-to-wire harness connections
• General electronic equipment signal routing

Headers, Male Pins Procurement Notes

Verify the specific datasheet version to confirm material specifications and compliance status. Ensure the required pin count matches the 12-position requirement. Confirm that the 600VAC rating aligns with the target circuit voltage. Check for any recent product change notifications affecting dimensions or materials.

Headers, Male Pins Selection Notes

Select this component when a shrouded, single-row header is required for board-to-wire applications. The 4.14mm pitch dictates the spacing constraints on the PCB layout. Consider the through-hole mounting method against available surface area and mechanical stress requirements. Verify compatibility with mating cable assemblies or wire gauges.

Headers, Male Pins Part Context

This part belongs to the TE Connectivity AMP Connectors portfolio, which specializes in reliable interconnection solutions. The series typically includes various pin counts and configurations within the same pitch family. These connectors are designed for industrial and commercial applications requiring durable electrical connections.

Headers, Male Pins Replacement Considerations

Consult official TE Connectivity substitution guides for verified alternatives. Generic equivalents may not match the shrouded envelope or pitch specifications.
