1-794065-1

$2.93

Description：CONN HEADER VERT 8POS 4.14MM
Series：Mini-Universal MATE-N-LOK
Mfr：TE Connectivity AMP Connectors
Package：Bulk

SKU:d7604ae35efc Category: Headers, Male Pins Brand: TE Connectivity AMP Connectors

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

1-794065-1 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists TE Connectivity AMP Connectors. Its product description is CONN HEADER VERT 8POS 4.14MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 1-794065-1

Description：CONN HEADER VERT 8POS 4.14MM
Series：Mini-Universal MATE-N-LOK
Mfr：TE Connectivity AMP Connectors
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.163" (4.14mm)
Number of Positions：8
Number of Rows：2
Row Spacing - Mating：0.163" (4.14mm)
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Locking Ramp
Contact Length - Mating：-
Contact Length - Post：0.175" (4.45mm)
Overall Contact Length：-
Insulation Height：0.531" (13.50mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：30.0µin (0.76µm)
Contact Finish - Post：Tin
Contact Material：Brass
Insulation Material：Polyamide (PA), Nylon
Features：Board Lock
Operating Temperature：-20°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：White
Current Rating (Amps)：Varies by Wire Gauge
Voltage Rating：600VAC

Headers, Male Pins datasheet and documents for 1-794065-1

1-794065-1

Headers, Male Pins Overview

The 1-794065-1 is a pin header connector from the MATE-N-LOK series by TE Connectivity AMP Connectors. It features an 8-position, dual-row configuration with a 4.14 mm pitch spacing. Designed for wire-to-board applications, it utilizes through-hole straight termination. The contacts are gold-plated brass pins housed in a white nylon insulator rated UL 94 V-0.

Headers, Male Pins Feature Summary

Dual-row pin header design for high-density board connections
Gold-plated contacts ensure reliable signal transmission
Nylon housing provides structural integrity and flame resistance

Headers, Male Pins Applications

Wire-to-board interconnections
General electronic equipment
Industrial control systems

Headers, Male Pins Procurement Notes

Verify the specific datasheet version to confirm current RoHS compliance status and material certifications. Ensure the ordering suffix matches the required contact plating and housing color specifications. Cross-reference the manufacturer part number with authorized distributor catalogs to confirm availability and lead times before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a dual-row, 8-position header with a 4.14 mm pitch is required. It is suitable for through-hole mounting on PCBs where gold-plated contacts offer corrosion resistance. Consider the MATE-N-LOK series compatibility for mating connectors and housing accessories.

Headers, Male Pins Part Context

This connector belongs to the MATE-N-LOK family, known for robust power and signal distribution. TE Connectivity AMP Connectors manufactures this line, leveraging decades of expertise in terminal and connector technology. The series supports various configurations for diverse industrial and commercial applications.

Headers, Male Pins Replacement Considerations

Compatible alternatives within the same MATE-N-LOK series include 1-794066-1 (12-position) and 1-794079-1 (24-position). Verify mechanical dimensions and electrical ratings before substitution.
