1-794619-6

Headers, Male Pins Overview

The 1-794619-6 is a dual-row header connector from the Micro MATE-N-LOK series, designed for board-to-board or board-to-wire applications. It features a 3.00mm (0.118 inch) pitch and offers 15 positions. The contacts are gold-plated to ensure reliable signal transmission in sensitive environments. Constructed with a plastic housing and board lock mechanism, it supports through-hole mounting with right-angle orientation. This component is engineered for high-density interconnects requiring robust mechanical stability and consistent electrical performance.

Headers, Male Pins Feature Summary

• Gold-plated contact surfaces provide enhanced corrosion resistance and stable conductivity for critical signal paths.
• Integrated plastic board lock mechanism secures the connector firmly to the printed circuit board during operation.
• Right-angle through-hole design facilitates efficient space utilization and optimized routing within compact electronic assemblies.

Headers, Male Pins Applications

• Computer peripheral equipment interconnects
• Business machine internal wiring systems
• Entertainment center component connections

Headers, Male Pins Procurement Notes

Verify that the specific ordering suffix matches the required contact plating and pin count configuration. Confirm that the right-angle orientation aligns with the PCB layout requirements. Ensure compatibility with the mating receptacle housing within the same Micro MATE-N-LOK family. Check for any specific handling instructions regarding the delicate gold-plated contacts during assembly.

Headers, Male Pins Selection Notes

Select this model when high-frequency signal integrity is paramount due to the gold plating option. Choose the right-angle form factor to accommodate spatial constraints on the circuit board. Consider the dual-row density for maximizing connection points within a limited footprint. Ensure the through-hole mounting method suits the manufacturing process and board thickness specifications.

Headers, Male Pins Part Context

This component belongs to the Micro MATE-N-LOK series, known for its versatility in low-to-medium current applications. The series utilizes a 3.00mm pitch, balancing density with ease of assembly. TE Connectivity AMP Connectors designs these components to meet rigorous industrial standards for reliability and durability in consumer and commercial electronics.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 15-position, 3.00mm pitch headers from the Micro MATE-N-LOK family, such as part number 1-794619-0, provided the contact plating and mounting orientation match the original design requirements.
