Headers, Receptacles, Female Sockets Overview

The Molex part number 22162101 corresponds to a pre-crimped jumper wire assembly. This component features a pin-to-pin configuration with a specified length of 10 inches (254.0 mm). The conductors utilize 22 AWG gauge wire, which is finished in a slate color. The termination method involves pre-crimping technology, ensuring consistent mechanical and electrical connections without the need for on-site crimping tools during assembly.

Headers, Receptacles, Female Sockets Feature Summary

• Pre-crimped construction for simplified assembly
• Pin-to-pin connectivity design
• Slate-colored 22 AWG conductor insulation

Headers, Receptacles, Female Sockets Applications

• Internal circuit board interconnections
• Prototype development wiring
• Low-voltage signal routing

Headers, Receptacles, Female Sockets Procurement Notes

Verify the exact suffix codes against official Molex documentation to confirm specific material properties and termination standards. Ensure compatibility with mating connectors regarding contact size and housing dimensions. Cross-reference the 22 AWG specification with system current requirements to prevent overheating or voltage drop issues in the final application environment.

Headers, Receptacles, Female Sockets Selection Notes

Select this jumper wire when a fixed-length, pre-terminated solution is required for internal device wiring. The 22 AWG gauge offers a balance between flexibility and current capacity suitable for low-power applications. The pre-crimped nature reduces assembly time compared to custom-cut and terminated wires, making it efficient for production runs requiring consistent lead lengths.

Headers, Receptacles, Female Sockets Part Context

This component belongs to Molex's line of pre-crimped jumper wires, designed for rapid integration into electronic assemblies. It serves as a direct replacement for field-cut wires, providing standardized electrical paths within devices. The product supports manufacturing efficiency by eliminating the need for separate crimping operations during the assembly phase.

Headers, Receptacles, Female Sockets Replacement Considerations

Consult official Molex substitution guides for equivalent jumper wire assemblies with matching 22 AWG specifications and 10-inch lengths. Verify that alternative parts maintain identical pin-to-pin configurations and slate insulation colors if visual identification is critical for the assembly process.
