2450316-1

Edgeboard Connectors Overview

The TE Connectivity AMP Connectors part number 2450316-1 is a high-speed interconnect assembly designed for signal integrity applications. It features an 85 Ohm impedance specification and contains 56 positions. The connector utilizes a silver contact finish to ensure reliable conductivity. This component is classified as a card edge connector assembly, intended for surface mount or board-level integration where controlled impedance is critical for data transmission performance.

Edgeboard Connectors Feature Summary

• Designed with an 85 Ohm impedance characteristic for high-speed signal integrity
• Features a silver-plated contact finish for enhanced conductivity
• Configured as a 56-position assembly for dense signal routing

Edgeboard Connectors Applications

• High-speed digital signal transmission systems
• Telecommunications equipment requiring controlled impedance
• Industrial control boards with high-frequency data requirements

Edgeboard Connectors Procurement Notes

Verify the exact suffix and revision level against the manufacturer's latest datasheet before ordering. Confirm that the 85 Ohm impedance requirement matches the target PCB trace design. Ensure compatibility with mating connectors and verify that the 56-position configuration aligns with the specific circuit layout needs.

Edgeboard Connectors Selection Notes

Select this component when a precise 85 Ohm impedance is required for differential or single-ended high-speed signals. The 56-position count supports moderate density applications. Consider the silver finish for environments where superior electrical contact is prioritized over gold durability. Validate mechanical fit within the available board space constraints.

Edgeboard Connectors Part Context

This part belongs to the TE Connectivity AMP Connectors portfolio, specifically within the card edge connector category. It serves as a specialized interconnect solution distinct from standard I/O connectors, focusing on maintaining signal quality in high-performance electronic assemblies.

Edgeboard Connectors Replacement Considerations

No publicly confirmed substitute part numbers are available in the provided documentation. Verify if generic 85 Ohm 56-position alternatives meet the specific mechanical and electrical tolerances before considering cross-referencing.
