305-068-521-512

$11.38

Description：CONN EDGE DUAL FMALE 68POS 0.156
Series：305
Mfr：EDAC Inc.
Package：Bulk

SKU:459779c9017e Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

305-068-521-512 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 68POS 0.156. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 305-068-521-512

Description：CONN EDGE DUAL FMALE 68POS 0.156
Series：305
Mfr：EDAC Inc.
Package：Bulk
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：34
Number of Positions：68
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.156" (3.96mm)
Read Out：Dual
Features：-
Mounting Type：Panel Mount, Through Hole
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Semi Bellows
Color：Green
Flange Feature：Flush Mount, Side Opening, Unthreaded, 0.128" (3.25mm) Dia
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 305-068-521-512

305-068-521-512

Edgeboard Connectors Overview

The EDAC Inc. 305-068-521-512 is a standard card edge connector from the 305 Series, designed for dual-row applications with 68 positions. It features a 0.156-inch (3.96 mm) contact pitch and utilizes gold-plated copper alloy contacts for reliable signal transmission. The component supports panel mount installation via through-hole solder termination. It accommodates board thicknesses within specified ranges and operates reliably in temperatures from -40°C to +105°C. The housing is constructed from green thermoplastic polyester, providing robust insulation and mechanical stability for industrial interconnect requirements.

Edgeboard Connectors Feature Summary

Dual-row configuration with 68 positions for high-density connectivity
Gold-plated copper alloy contacts ensure durable electrical performance
Thermoplastic polyester housing provides stable insulation properties
Panel mount design facilitates secure vertical installation

Edgeboard Connectors Applications

Industrial control system interconnections
Telecommunications equipment backplanes
Automotive electronic module interfaces
Test and measurement instrument connections

Edgeboard Connectors Procurement Notes

Verify that the specific ordering suffix matches the required contact finish and housing color specifications. Confirm that the panel cutout dimensions align with the connector's flange characteristics to ensure proper fit. Check for any regional distribution restrictions or RoHS compliance documentation requirements before finalizing procurement orders to ensure regulatory adherence.

Edgeboard Connectors Selection Notes

Select this connector when a dual-row interface with a 3.96 mm pitch is required for vertical panel mounting. Ensure the mating card edge thickness falls within the compatible range defined by the series specifications. Consider the operating temperature limits and current ratings to verify suitability for the intended application environment and load conditions.

Edgeboard Connectors Part Context

This component belongs to the EDAC 305 Series of standard card edge connectors. The series offers various position counts and spacing options to accommodate different circuit board designs. The 305 Series is characterized by its use of thermoplastic polyester housings and gold-plated contacts, providing a balance of durability and electrical reliability for general-purpose interconnect applications.
