395-020-524-503

Edgeboard Connectors Overview

The EDAC Inc. 395-020-524-503 is a standard card edge connector from the 395 series, designed for vertical panel mounting applications. It features a single row of twenty female contacts with a 0.100-inch (2.54mm) pitch. The connector utilizes gold-plated copper alloy terminals and a black thermoplastic polyester insulator. It is specified for dual-edge card compatibility and supports a board thickness range of 0.054 to 0.070 inches.

Edgeboard Connectors Feature Summary

• Vertical panel mount configuration for secure installation
• Gold-plated contact surfaces for reliable signal transmission
• Thermoplastic polyester insulation for thermal stability

Edgeboard Connectors Applications

• Industrial control systems
• Telecommunications equipment
• Automotive electronics

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against official EDAC documentation to ensure correct termination type and plating specifications. Confirm that the selected variant matches the required card edge profile and mounting style for the target application. Cross-reference the manufacturer part number with authorized distributor catalogs to validate authenticity and current availability status before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this component when a vertical, single-row connection is required for dual-edge cards. Ensure the design accommodates the 0.100-inch pitch and compatible board thickness. Verify that the operating temperature range meets system requirements and that the panel mounting style aligns with the mechanical enclosure design constraints.

Edgeboard Connectors Part Context

This component belongs to the EDAC 395 series of standard card edge connectors. The series provides various position counts and mounting options for diverse electronic interconnection needs. The 395-020 designation indicates a twenty-position variant within this established product line, offering standardized dimensions and electrical characteristics for general-purpose circuit board connections.

Edgeboard Connectors Replacement Considerations

Consult official EDAC documentation for verified substitute part numbers within the 395 series or other compatible families. Do not assume interchangeability based on generic specifications alone. Validate all mechanical and electrical parameters against the original design requirements before considering any alternative components.
