Description：CONN HEADER VERT 14POS 2.54MM
Series：450
Mfr：Preci-Dip
Package：Bulk

SKU:22771b070bd8 Category: Headers, Male Pins Brand: Preci-Dip

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

450-80-214-00-006101 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Preci-Dip. Its product description is CONN HEADER VERT 14POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 450-80-214-00-006101

Description：CONN HEADER VERT 14POS 2.54MM
Series：450
Mfr：Preci-Dip
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：14
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.141" (3.60mm)
Contact Length - Post：0.114" (2.90mm)
Overall Contact Length：0.394" (10.00mm)
Insulation Height：0.110" (2.79mm)
Contact Shape：Circular
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：-
Contact Finish - Post：Tin
Contact Material：Brass
Insulation Material：Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：150VDC

Headers, Male Pins datasheet and documents for 450-80-214-00-006101

450-80-214-00-006101

Headers, Male Pins Overview

The Preci-Dip 450-80-214-00-006101 is a two-row, straight pin header connector designed for board-to-board applications. It features a 2.54 mm (0.100 inch) pitch and accommodates 14 positions. The component utilizes through-hole termination for secure PCB mounting. Rated at 3A current and 150V DC voltage, it employs brass contacts with tin plating on both the mating and post sections. The housing is constructed from black PCT polyester reinforced with glass fiber, meeting UL94 V-0 flammability standards. Operating temperature ranges from -55°C to 125°C.

Headers, Male Pins Feature Summary

Push-pull locking mechanism ensures secure connection retention
Tin-plated brass contacts provide reliable conductivity
Glass-fiber reinforced PCT insulation offers thermal stability

Headers, Male Pins Applications

Board-to-board interconnects in industrial control systems
Signal routing in telecommunications equipment
Internal connections within consumer electronic devices

Headers, Male Pins Procurement Notes

Verify the specific contact length requirements against the mating header specifications before procurement. Confirm that the tin-plated finish aligns with the intended environmental conditions and soldering processes. Ensure the push-pull locking style matches the assembly tooling and mechanical constraints of the target application design.

Headers, Male Pins Selection Notes

Select this model when a standard 2.54mm pitch through-hole header with a push-pull lock is required. Consider the 14-position count and two-row configuration for space-constrained layouts. Evaluate the tin plating against gold options if higher corrosion resistance or frequent mating cycles are necessary for the specific operational environment.

Headers, Male Pins Part Context

This part belongs to the Preci-Dip 450 series, which defines a family of standard height pin headers. The series is characterized by its versatility in board-to-board connectivity and availability in various position counts. The 450-80 suffix indicates the specific row count, pitch, and locking style configuration within this product line.
