530480360

$0.41

Description：HDR RA 3 CIRC 1.25 DIP TH
Series：PicoBlade 53048
Mfr：Molex
Package：Tray

SKU:be81026b92b7 Category: Headers, Male Pins Brand: Molex

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

530480360 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Molex. Its product description is HDR RA 3 CIRC 1.25 DIP TH. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 530480360

Description：HDR RA 3 CIRC 1.25 DIP TH
Series：PicoBlade 53048
Mfr：Molex
Package：Tray
Connector Type：Header
Contact Type：Male Blade
Pitch - Mating：0.049" (1.25mm)
Number of Positions：3
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Detent Lock
Contact Length - Mating：-
Contact Length - Post：0.091" (2.30mm)
Overall Contact Length：-
Insulation Height：0.138" (3.50mm)
Contact Shape：Rectangular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：Flash
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Polyamide (PA), Nylon
Features：-
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Natural
Current Rating (Amps)：Varies by Wire Gauge
Voltage Rating：125V

Headers, Male Pins datasheet and documents for 530480360

530480360

Headers, Male Pins Overview

The Molex 530480360 is a PicoBlade series PCB header featuring a single row of three positions with a 1.25mm pitch. It utilizes right-angle through-hole mounting for secure board attachment. The connector supports wire-to-board applications and includes gold flash plating on the contact surfaces to ensure reliable signal transmission. Rated for 125V, it accommodates various current ratings dependent on the selected wire gauge.

Headers, Male Pins Feature Summary

Single-row right-angle configuration for space-efficient PCB layouts
Gold flash plating on contacts for enhanced conductivity and corrosion resistance
Through-hole mounting method ensures stable mechanical connection

Headers, Male Pins Applications

Wire-to-board interconnections in consumer electronics
Signal routing in compact printed circuit boards
Industrial control system interface modules

Headers, Male Pins Procurement Notes

Verify that the specified part number matches the required pin count and pitch before ordering. Confirm that the gold flash plating specification aligns with your environmental requirements. Ensure compatibility with mating receptacles from the same PicoBlade family. Check datasheet details regarding current derating curves relative to ambient temperature conditions.

Headers, Male Pins Selection Notes

Select this component when a low-profile, high-density connection is required for right-angle board installations. The 1.25mm pitch allows for tighter spacing compared to standard headers. Consider the through-hole mounting style if surface-mount alternatives are unsuitable for the assembly process or mechanical stress requirements.

Headers, Male Pins Part Context

This component belongs to the Molex PicoBlade family, designed for high-density interconnects. It serves as a male header variant within the broader connector ecosystem, providing a standardized interface for mating with compatible female housings and terminals.
