Overview

The SICK ATM60-D4H13X13 is an incremental encoder designed for industrial automation. It provides a resolution of 8,192 pulses per revolution (ppr). The device utilizes a hollow shaft design with a diameter of 13 mm and a maximum bore size of 13 mm. It operates within a supply voltage range of 4.75 V to 5.25 V DC. The unit features TTL output signals in quadrature format.

Feature Summary

• Incremental position sensing via quadrature signal outputs
• Hollow shaft mechanical construction for direct mounting
• TTL interface compatibility for standard control systems

Applications

• Position feedback in automated packaging machinery
• Rotational monitoring in printing press systems
• Drive control integration in textile manufacturing equipment

Procurement Notes

Verify the specific suffix codes against official SICK documentation to confirm electrical interface and mechanical dimensions. Ensure the order matches the required resolution and voltage specifications for the target application environment. Cross-reference the part number with current manufacturer catalogs to validate availability and technical revisions before procurement.

Selection Notes

Select this model when a high-resolution incremental encoder with a hollow shaft is required for space-constrained installations. Confirm that the host system supports TTL input levels and that the operating temperature range aligns with the environmental conditions of the installation site.

Part Context

This component belongs to the ATM60 series of rotary encoders manufactured by SICK. The series is engineered for robust performance in demanding industrial environments. The specific model integrates precise optical sensing technology with durable mechanical components to ensure reliable data transmission during continuous operation.

Replacement Considerations

Consult official SICK substitution guides for verified equivalents. Generic replacements may not match the specific TTL interface or hollow shaft dimensions required for seamless integration into existing machinery setups.
