6050703

Overview

The SICK model 6050703 is an IQ40 series photoelectric sensor with a square, short housing measuring 40 mm x 40 mm x 66 mm. It operates as a DC 3-wire PNP normally closed output device with a switching distance of 20 mm and a secured switching distance of 16.2 mm. The unit features an IP67 protection rating and connects via a rotatable M12 connector. Designed for flush mounting in metal, it supports switching frequencies up to 100 Hz.

Feature Summary

• Compact square housing design suitable for space-constrained installations
• Flush mounting capability within metal surfaces
• Integrated background suppression for reliable object detection
• Rotatable M12 connector for flexible cable routing

Applications

• Automated assembly line component positioning
• Packaging machine object presence verification
• Conveyor belt item detection in confined spaces

Procurement Notes

Verify the specific ordering suffix against the official SICK product catalog to confirm interface type and output configuration. Ensure the selected variant matches the required voltage range and switching distance specifications for the intended application environment. Cross-reference the part number with current technical documentation to validate compatibility with existing control systems.

Selection Notes

Select this sensor when a compact form factor and flush mounting are required for metal integration. Consider the 20 mm switching distance and PNP output characteristics for compatibility with standard PLC inputs. Evaluate the IP67 rating against environmental conditions such as dust or moisture exposure during operation.

Part Context

This component belongs to the IQ40 product family, characterized by miniature dimensions and standardized mounting configurations. The series utilizes advanced ASIC technology for signal processing, ensuring high reliability and consistent performance across various industrial automation tasks requiring precise proximity detection.

Replacement Considerations

Consult the official SICK replacement guide for direct equivalents. Verify mechanical dimensions and electrical pin assignments before substituting with other models to ensure seamless integration without modifying existing wiring or mounting hardware.
