61-238/QK2C-B50632FAGB2/ET

LED Indication - Discrete Overview

The Everlight 61-238/QK2C-B50632FAGB2/ET is a single color surface mount LED emitting cool white light. It utilizes a water clear lens and features a T-1, 3mm package configuration with six SMT pins. The device supports infrared reflow soldering methods and complies with RoHS standards. It operates within a temperature range of -40 °C to 85 °C, with a maximum forward current of 0.03 A and a nominal luminous intensity of 5800 mcd.

LED Indication - Discrete Feature Summary

• Supports infrared reflow soldering processes
• Features a wide viewing angle design
• Complies with RoHS environmental standards

LED Indication - Discrete Applications

• General lighting systems
• Decorative lighting applications
• Entertainment lighting setups

LED Indication - Discrete Procurement Notes

Verify the specific suffix against official Everlight documentation to confirm exact optical characteristics. Confirm availability status through authorized distributors as supply constraints may apply. Ensure compliance with local environmental regulations regarding lead-free components before finalizing procurement orders.

LED Indication - Discrete Selection Notes

Select this component for designs requiring high-intensity cool white illumination in compact surface mount layouts. Consider the 6-pin lead frame package for improved thermal management compared to standard PLCC types. Verify that the operating voltage and current limits align with the target circuit requirements.

LED Indication - Discrete Part Context

This part belongs to the Everlight 61-238 series of super-luminosity white LEDs. The series is characterized by its use of special phosphors combined with blue LEDs to achieve white light output. These devices are engineered for applications demanding high brightness within small form factors.

LED Indication - Discrete Replacement Considerations

Consult official Everlight substitution guides for compatible alternatives. Cross-reference pin configurations and luminous intensity specifications when evaluating potential replacement parts.
