75160-132-08LF

Headers, Male Pins Overview

The 75160-132-08LF is an unshrouded header connector from the BergStik® series, manufactured by Amphenol ICC (FCI). It features a male pin configuration with eight positions arranged in a single row. The connector utilizes a 0.100-inch (2.54mm) pitch and is designed for through-hole mounting with a straight solder termination. Constructed with phosphor bronze contacts and black thermoplastic insulation, it offers a rated current of 5A and a voltage rating of 110V. The operating temperature range spans from -65°C to +130°C, and the unit complies with RoHS standards.

Headers, Male Pins Feature Summary

• BergStik® series design providing reliable board-to-board interconnection solutions
• Gold GXT™ contact plating ensures durable electrical performance and corrosion resistance
• Straight through-hole mounting style facilitates standard PCB assembly processes
• UL94 V-0 flammability rating for enhanced safety in electronic assemblies

Headers, Male Pins Applications

• General-purpose electronic circuit board interconnections
• Industrial control system signal routing
• Consumer electronics internal component linking
• Communication equipment board connections

Headers, Male Pins Procurement Notes

Verify the specific part number suffix to confirm lead-free status and packaging details. Check manufacturer documentation for current production status, as components may be subject to obsolescence notices. Ensure compatibility with mating receptacles regarding pin count and pitch dimensions before procurement.

Headers, Male Pins Selection Notes

Select this component when a single-row, unshrouded male header is required for vertical or straight board mounting. Confirm that the 2.54mm pitch aligns with the target PCB layout and that the 5A current rating meets the application's electrical requirements. Consider the straight orientation for space-constrained environments.

Headers, Male Pins Part Context

This component belongs to the BergStik® family of connectors, which are widely recognized for their versatility in general interconnect applications. The 75160 base series encompasses various configurations, including different pin counts and insulation heights, allowing for flexible design integration across diverse electronic products.

Headers, Male Pins Replacement Considerations

Compatible substitutes within the same series include 75160-122-08LF and 75160-127-08LF. Verify that alternative parts match the required pin count, pitch, and mounting style before substitution.

Headers, Male Pins FAQ

What is the contact material used in this connector?

The contacts are made of phosphor bronze, which provides good elasticity and conductivity.

Is this connector RoHS compliant?

Yes, the 75160-132-08LF is lead-free and RoHS compliant.
