782482/33VC

$1.79

Description：XFRMR CONV ADM2482 3.3V IN
Series：782482
Mfr：Murata Power Solutions Inc.
Package：Tube

SKU:e08246ad1a0a Category: Pulse Transformers Brand: Murata Power Solutions Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

782482/33VC is listed in the Pulse Transformers range at ChipApex. The manufacturer field lists Murata Power Solutions Inc.. Its product description is XFRMR CONV ADM2482 3.3V IN. Review the specifications below when checking this part for your BOM.

Pulse Transformers specifications for 782482/33VC

Description：XFRMR CONV ADM2482 3.3V IN
Series：782482
Mfr：Murata Power Solutions Inc.
Package：Tube
Transformer Type：Isolation and Data Interface (Encapsulated)
Inductance：310µH
ET (Volt-Time)：-
Turns Ratio - Primary:Secondary：1CT:1.33CT
Mounting Type：Through Hole
Size / Dimension：0.360" L x 0.385" W (9.14mm x 9.77mm)
Height - Seated (Max)：0.250" (6.35mm)
Operating Temperature：-40°C ~ 85°C
Grade：-
Qualification：-

Pulse Transformers datasheet and documents for 782482/33VC

782482/33VC

Pulse Transformers Overview

The Murata Power Solutions 782482/33VC is a through-hole encapsulated pulse transformer designed for isolated RS-485 and RS-422 interfaces. It features a primary inductance of 310µH and a turns ratio of 1:1.33. The component supports a primary voltage rating of 3.3V and a secondary voltage rating of 3.3V. Its physical dimensions are 9.77mm in length, 9.14mm in width, and 6.35mm in height. This device is specifically engineered to provide low electromagnetic interference (EMI) performance when used with Analog Devices ADM2482/7 transceiver chipsets.

Pulse Transformers Feature Summary

Engineered for low electromagnetic interference (EMI) performance
Designed specifically for Analog Devices ADM2482/7 transceiver chipsets
Provides galvanic isolation for RS-485 and RS-422 communication interfaces

Pulse Transformers Applications

Isolated RS-485 interface implementation
Isolated RS-422 interface implementation
Data communication systems utilizing Analog Devices ADM2482/7 transceivers

Pulse Transformers Procurement Notes

Verify the specific part number suffix against official Murata documentation to ensure correct configuration. Confirm that the required isolation voltage and inductance parameters align with the target circuit design specifications before finalizing procurement orders.

Pulse Transformers Selection Notes

Select this component when designing circuits requiring isolation for RS-485 or RS-422 protocols using Analog Devices ADM2482/7 chips. Ensure the PCB layout accommodates the specified through-hole package dimensions and thermal requirements for reliable operation.

Pulse Transformers Part Context

This component belongs to the 782482 series of converter transformers launched by Murata Power Solutions. These devices are specialized for providing isolated data interfaces, addressing the need for robust communication in industrial and commercial environments where signal integrity and noise immunity are critical.
