800-10-049-30-001101

Headers, Male Pins Overview

The Preci-Dip 800-10-049-30-001101 is a single-row male header connector from the 800 series, designed for surface-mount applications. It features 49 positions with a 2.54 mm pitch and operates within a temperature range of -55°C to 125°C. The contacts are made of brass with tin plating, housed in black PCT insulation rated UL94 V-0. Rated at 3A and 150V DC, this unshrouded connector utilizes solder tail termination for reliable PCB attachment.

Headers, Male Pins Feature Summary

• Surface-mount right-angle design for compact board integration
• High-density 49-position configuration on standard 2.54 mm spacing
• Robust thermal stability across extended industrial temperature ranges

Headers, Male Pins Applications

• High-pin-count board-to-board interconnects
• Industrial control system signal routing
• Consumer electronics internal module connections

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against manufacturer documentation to confirm exact physical dimensions and termination style. Ensure compatibility with automated surface-mount assembly processes. Cross-reference the full part number to validate insulation material ratings and current capacity requirements for the target application environment.

Headers, Male Pins Selection Notes

Select this component when high-density surface-mount connectivity is required. The 49-position count supports complex signal routing in limited spaces. Verify that the 2.54 mm pitch aligns with mating connector specifications. Confirm that the surface-mount form factor suits the manufacturing workflow and board layout constraints.

Headers, Male Pins Part Context

This part belongs to the Preci-Dip 800 series, which offers various pin counts and mounting styles. The 800-10 variant specifically denotes surface-mount construction. This series provides standardized dimensions for consistent mechanical fit across diverse electronic assemblies requiring reliable electrical connections.

Headers, Male Pins Replacement Considerations

Direct substitutes include other 49-position 2.54 mm SMD headers from compatible manufacturers. Verify identical pin count, pitch, and mounting orientation before substitution. Ensure mating connector compatibility and environmental rating equivalence.
