801-87-047-20-101101

Headers, Receptacles, Female Sockets Overview

The Preci-Dip 801-87-047-20-101101 is a 24-position PCB socket connector from the 801 series. It features a 0.200" (5.08mm) pitch and utilizes through-hole, right-angle mounting. The contacts are gold-plated for the mating interface and tin-plated for the column termination. Rated for 3A current, it operates within a temperature range of -55°C to +125°C. The housing is black PCT with UL94 V-0 flammability rating.

Headers, Receptacles, Female Sockets Feature Summary

• Right-angle through-hole design for board-to-board interconnection
• Gold-plated contact surfaces ensure reliable signal transmission
• High-temperature resistant PCT insulation material

Headers, Receptacles, Female Sockets Applications

• Industrial control system circuit boards
• Communication equipment backplanes
• Consumer electronics internal connections

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific pin count and pitch against schematic requirements before ordering. Confirm that the right-angle orientation matches the mechanical layout constraints. Ensure the operating environment temperature falls within the specified -55°C to +125°C range. Check for any specific RoHS compliance documentation if required by your supply chain standards.

Headers, Receptacles, Female Sockets Selection Notes

Select this model when a 24-pin connection with a 5.08mm spacing is required. The right-angle form factor is suitable for compact vertical stacking or edge mounting scenarios. Consider the 3A current rating for power distribution needs. Compare against other 801 series variants if different pin counts or straight configurations are needed.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Preci-Dip 801 series of rectangular connectors. The series offers various configurations including different pin counts and mounting styles. The 801-87 suffix typically denotes specific housing and termination characteristics within this product line, designed for robust electronic interconnections.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible substitutes include other 24-position, 0.200" pitch right-angle sockets from manufacturers such as Samtec or Molex. Ensure the replacement maintains the same current rating and temperature specifications. Verify that the terminal plating and housing material meet the original application requirements.
