892-80-018-20-001101

Headers, Male Pins Overview

The Preci-Dip 892-80-018-20-001101 is a right-angle male header connector designed for through-hole mounting. It features an 18-position configuration with a 2.54mm (0.100 inch) pitch across two rows. The contacts are made of brass with tin plating, rated for 3A current and 150VDC voltage. Constructed from black glass-reinforced polyamide insulation with UL94 V-0 flammability rating, it operates within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Right-angle board-to-board interconnection design
• Through-hole termination for secure PCB mounting
• Tin-plated brass contacts for reliable conductivity

Headers, Male Pins Applications

• General electronic circuit board interconnections
• Industrial control system modules
• Consumer electronics assembly

Headers, Male Pins Procurement Notes

Verify the specific part number against manufacturer catalogs to ensure compatibility with mating connectors. Confirm that the required pin count and pitch match the design specifications. Check for RoHS compliance status if environmental regulations apply to the end product. Ensure storage conditions maintain component integrity prior to assembly.

Headers, Male Pins Selection Notes

Select this connector when a low-profile, right-angle header is required for dense board layouts. The 2.54mm pitch offers standard spacing compatibility with common mating solutions. Consider the 3A current rating for power distribution needs within the specified voltage limits. Evaluate thermal requirements against the -55°C to 125°C operating range.

Headers, Male Pins Part Context

This component belongs to the Preci-Dip 892 series of rectangular connectors. The series provides various pin counts and configurations for different application densities. The 892-80 suffix indicates a right-angle orientation with specific contact length characteristics typical of this family.

Headers, Male Pins Replacement Considerations

Compatible mating sockets include Preci-Dip part numbers such as 893-87-018-10-001101 or 893-83-018-10-001101. Verify that substitute headers maintain identical pitch, row count, and mounting style.
