895-010-559-508

$51.73

Description：CONN EDGE DUAL FMALE 10POS 0.100
Series：895
Mfr：EDAC Inc.
Package：Bulk

SKU:413978695ebb Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

895-010-559-508 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 10POS 0.100. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 895-010-559-508

Description：CONN EDGE DUAL FMALE 10POS 0.100
Series：895
Mfr：EDAC Inc.
Package：Bulk
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：5
Number of Positions：10
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.100" (2.54mm)
Read Out：Dual
Features：-
Mounting Type：Through Hole, Right Angle
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Cantilever
Color：Black
Flange Feature：Top Mount Opening, Threaded Insert, 4-40
Operating Temperature：-40°C ~ 125°C

Edgeboard Connectors datasheet and documents for 895-010-559-508

895-010-559-508

Edgeboard Connectors Overview

The EDAC Inc. 895-010-559-508 is a dual-edge female card edge connector featuring ten positions with a 0.100-inch (2.54mm) pitch. Designed for through-hole termination, it utilizes gold-plated copper alloy contacts and a black polyphenylene sulfide (PPS) insulator. The component supports PCB thicknesses ranging from 0.054 to 0.070 inches and operates within a temperature range of -40°C to 125°C.

Edgeboard Connectors Feature Summary

Dual-edge female configuration for reliable board insertion
Gold-plated contacts ensure stable electrical performance
High-temperature PPS insulation material for durability

Edgeboard Connectors Applications

Industrial control systems
Medical equipment interfaces
Consumer electronics modules

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against official EDAC documentation to confirm exact contact plating thickness and flange specifications. Ensure compatibility with target PCB thickness limits before procurement. Confirm RoHS compliance status via current manufacturer datasheets to meet regulatory requirements for the intended application environment.

Edgeboard Connectors Selection Notes

Select this model when a low-profile, double-sided connection is required for thin circuit boards. The 0.100-inch pitch accommodates standard digital signal routing. Verify that the housing height and mounting style align with enclosure constraints. Consider thermal ratings if operating in high-temperature industrial environments.

Edgeboard Connectors Part Context

Part of the EDAC 895 Series, designed for general-purpose interconnect applications. The series offers various pin counts and mounting options. This specific variant focuses on compact dual-edge connectivity for standard thickness boards, balancing mechanical stability with electrical reliability in space-constrained designs.

Edgeboard Connectors Replacement Considerations

Consult EDAC official substitution guides for direct equivalents. Generic card edge connectors may differ in flange dimensions or contact spring force. Verify mating board slot tolerances and insulation material properties before substituting with non-OEM components.
