929667-01-14-I

Headers, Male Pins Overview

The 3M 929667-01-14-I is a pin strip connector from the 929 series, designed for board-to-board and wire-to-board applications. It features a 2.54 mm pitch with 14 contacts in a single row. The connector utilizes through-hole termination and offers vertical or horizontal mounting orientations. Contact surfaces are available in gold or tin/lead options to ensure conductivity and corrosion resistance. The design includes solder pillars to facilitate wave soldering processes and optional tab stops for stable PCB pin retention.

Headers, Male Pins Feature Summary

• Stackable design expands engineering flexibility
• Solder pillars support wave soldering production
• Tab stops enhance through-board connection stability

Headers, Male Pins Applications

• Board-to-board connections
• Wire-to-board connections
• Industrial automation systems
• Data center designs

Headers, Male Pins Procurement Notes

Verify the specific contact plating configuration (gold or tin/lead) required for your application against the datasheet specifications. Confirm that the insulation material meets the necessary thermal ratings for your manufacturing process. Ensure the mounting orientation aligns with the mechanical constraints of the assembly. Cross-reference the technical sheet number TS-0768 for complete regulatory and chemical compliance information before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a versatile, stackable pin strip is needed for prototyping or custom designs. The 929 series allows for flexible separation and customization. Choose based on the required contact count, orientation preference, and surface finish compatibility with mating connectors. Consider the availability of high-temperature PCT insulation if wave or infrared soldering is part of the production workflow.

Headers, Male Pins Part Context

This part belongs to the 3M 929 series pin strip family, which provides multi-purpose插针 options in single and double row configurations. The series supports both horizontal and vertical versions, offering design freedom for various electronic assemblies. Components in this line are characterized by their ability to be easily separated for customized lengths and their robust construction for reliable electrical interconnections.

Headers, Male Pins Replacement Considerations

Consult the official 3M replacement guide for direct substitutes. Verify that any alternative maintains the 2.54 mm pitch and compatible contact geometry.
