929834-07-34-RK

Headers, Male Pins Overview

The 3M 929834-07-34-RK is a vertical pin strip header connector from the 929 series, designed for board-to-board applications. It features a single row with 34 positions and a 2.54mm (0.100 inch) mating pitch. The connector utilizes through-hole termination for soldering to printed circuit boards. Contact materials consist of copper alloy with matte tin plating on both mating and post sections. The insulator is made of glass-reinforced PCT, rated UL94 V-0, supporting an operating temperature range of -40°C to 105°C. It has a square contact shape and a push-pull fastening style.

Headers, Male Pins Feature Summary

• Vertical pin strip design for direct PCB mounting
• Single-row configuration with break-away capability
• Matte tin plated contacts for reliable conductivity
• Glass-reinforced PCT insulation for thermal stability

Headers, Male Pins Applications

• Board-to-board interconnections
• Industrial automation systems
• Data center hardware assembly
• Electronic prototyping and testing

Headers, Male Pins Procurement Notes

Verify component authenticity against official 3M documentation due to potential supply chain variations. Confirm that the specific suffix matches the required pin count and plating specifications. Check RoHS compliance status as regulatory requirements may evolve. Ensure storage conditions maintain moisture sensitivity level 1 integrity prior to soldering processes.

Headers, Male Pins Selection Notes

Select this model when a single-row, 34-position vertical header is required for rigid board connections. Consider the 2.54mm pitch compatibility with standard mating connectors. Evaluate the through-hole termination method against surface-mount alternatives. Assess the thermal rating of the PCT insulation against peak soldering temperatures in the manufacturing workflow.

Headers, Male Pins Part Context

This component belongs to the 3M 929 series of Pin Strip connectors, which are characterized by their low-profile, stackable design. The series offers various pin counts and configurations to support flexible electronic assembly needs. These headers are engineered for high-density applications where space efficiency and mechanical stability are critical for long-term performance.

Headers, Male Pins Replacement Considerations

Direct substitutes include other 3M 929 series headers with identical 34-pin counts and 2.54mm pitch, such as the 929834-07-35-RK variant for adjacent pin configurations. Verify that any replacement maintains the same vertical orientation, through-hole termination, and tin-plated contact specifications to ensure mechanical and electrical compatibility.
