929836-09-29

Headers, Male Pins Overview

The 3M part number 929836-09-29 is a male pin header connector from the 929 series, designed for board-to-board or wire-to-board applications. It features a 2.54 mm (0.1 in) pitch and a dual-row configuration with 58 positions. The contacts are tin-plated copper alloy pins with a straight mounting angle suitable for through-hole soldering. Rated for 2.5 A current and 1.5 kV voltage, the unit utilizes black PBT insulation. This component is currently discontinued and no longer sold by distributors.

Headers, Male Pins Feature Summary

• Dual-row pin strip design with 2.54 mm spacing
• Tin-plated copper alloy contacts for reliable conductivity
• Through-hole installation with straight orientation
• High-temperature resistant PBT insulation material

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board connections
• Industrial automation circuitry
• Data center hardware assembly

Headers, Male Pins Procurement Notes

This specific component is officially discontinued and no longer available for purchase from authorized distributors. Verification of availability should be conducted directly with the manufacturer or legacy inventory sources. Procurement planning must account for end-of-life status, requiring immediate identification of alternative components to ensure supply chain continuity for existing designs.

Headers, Male Pins Selection Notes

Engineers selecting this component should note its discontinuation status. Design reviews must evaluate whether existing stock suffices for production needs or if a replacement header is required. Selection criteria should focus on matching the 2.54 mm pitch, dual-row format, and 58-position count while ensuring compatibility with the target PCB footprint and mating connector specifications.

Headers, Male Pins Part Context

Part of the 3M 929 series headers, which offer versatile single or dual-row options. These connectors support various plating finishes including gold, matte tin, and tin-lead. The series is engineered for high-temperature applications compatible with wave or infrared soldering processes, providing robust mechanical and electrical performance for demanding electronic environments.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Due to the discontinued status, engineers must identify equivalent connectors based on mechanical dimensions, electrical ratings, and pin configuration. Cross-referencing with other manufacturers' 2.54mm dual-row headers is recommended to maintain design integrity.
