AM2520SRC09

LED Indication - Discrete Overview

The Kingbright AM2520SRC09 is a subminiature surface-mount red LED with a 630nm peak wavelength and 20-degree viewing angle. It features a 2-SMD鸥翼 package, measuring 2.5mm x 2.0mm. The component operates with a typical forward voltage of 2.5V and a maximum DC forward current of 185mA. It delivers a luminous intensity of 2.4 cd at 20mA test current. The device is rated for a power dissipation of 75mW and functions within a temperature range of -40°C to 85°C.

LED Indication - Discrete Feature Summary

• Subminiature SMD form factor for compact circuit integration
• High luminous intensity output in red spectrum
• Standard 20-degree viewing angle for directional indication

LED Indication - Discrete Applications

• Panel status indication
• Instrument front panels
• Consumer electronics signaling

LED Indication - Discrete Procurement Notes

Verify availability as this specific part number is listed as obsolete by major distributors. Confirm that substitute components meet the required electrical parameters, specifically the 2.5V forward voltage and 2.4 cd intensity. Ensure the replacement package matches the 2-SMD鸥wing footprint to maintain PCB compatibility without redesigning the solder mask or copper layout.

LED Indication - Discrete Selection Notes

Select alternatives based on matching the 2.5V forward voltage drop and 185mA maximum current rating. The replacement must support the 2.5mm x 2.0mm dimensions and 20-degree beam width. Verify that the new component maintains the same water-clear lens transparency and operating temperature range to ensure consistent optical performance and thermal reliability in the target application environment.

LED Indication - Discrete Part Context

This component belongs to the AM2520 series of subminiature solid-state lamps manufactured by Kingbright. The series offers various color options including red, yellow, orange, and infrared variants. These LEDs are designed for high-density mounting on printed circuit boards, providing reliable visual feedback in space-constrained electronic devices while maintaining standard surface-mount processing compatibility.

LED Indication - Discrete Replacement Considerations

Kingbright lists available substitutes for this obsolete part. Ensure the selected replacement maintains identical pin configuration and mechanical dimensions.
