APB2012QBDCGKC
Search Product
Search Post
— IC芯片 | 连接器 | 传感器 | 被动器件 —
Consult the customer manager about the wholesale price.
consultation hotline：86-132-6715-2157
email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.
Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.
Product Detailed Parameters
- Description：LED BLUE/GREEN CLEAR CHIP SMD
- Series：-
- Mfr：Kingbright
- Package：Tape & Reel (TR),Cut Tape (CT)
- Color：Blue, Green
- Configuration：Bidirectional
- Lens Color：Colorless
- Lens Transparency：Clear
- Millicandela Rating：80mcd Blue, 50mcd Green
- Lens Style：Rectangle with Flat Top
- Lens Size：1.30mm x 1.25mm
- Voltage - Forward (Vf) (Typ)：3.3V Blue, 2.1V Green
- Current - Test：20mA Blue, 20mA Green
- Viewing Angle：150°
- Mounting Type：Surface Mount
- Wavelength - Dominant：465nm Blue, 570nm Green
- Wavelength - Peak：460nm Blue, 574nm Green
- Features：-
- Package / Case：0805 (2012 Metric)
- Supplier Device Package：Chip LED
- Size / Dimension：2.00mm L x 1.25mm W
- Height (Max)：1.10mm
- Grade：-
- Qualification：-
Download product information
Overview
The APB2012QBDCGKC is a blue and green bi-color LED indicator in a 0805 (2012 metric) surface-mount package. It features a common anode configuration with rectangular flat-top lenses. The blue element emits at 465nm with a typical forward voltage of 3.3V, while the green element operates at 570nm with a typical forward voltage of 2.1V. Both colors provide a millicandela rating of 300mcd under a 20mA test current. The component measures 2.00mm in length and 1.25mm in width.
Feature Summary
- Dual-color bi-LED structure combining blue and green emission sources within a single compact package
- Common anode electrical configuration for simplified circuit control
- Rectangular lens style with flat top design for directional light output
Applications
- Status indication on electronic circuit boards
- Visual signaling in consumer electronics devices
- Panel indicators for equipment power or mode states
Procurement Notes
Verify part authenticity through authorized Kingbright distributors. Confirm RoHS3 compliance status prior to assembly. Ensure ESD protection protocols are followed during handling due to sensitivity to electrostatic discharge and power surges. Check datasheet for moisture sensitivity classification before reflow soldering.
Selection Notes
Select this component when a dual-color status indicator is required in a limited space. The 0805 footprint suits high-density PCB layouts. Verify that the 3.3V blue and 2.1V green forward voltages align with the driving circuit capabilities. Consider the 15-degree viewing angle if precise beam directionality is necessary for the application.
Part Context
This part belongs to the Kingbright APBDA series of surface-mount LEDs. It utilizes InGaN technology for the blue source. The manufacturer maintains ISO 9001 and TS 16949 certifications. The product line supports automated production processes with strict quality controls.
Replacement Considerations
Consult official Kingbright documentation for verified substitutes. The KP-2012QBC-D is referenced in related technical materials. Verify pinout compatibility and electrical parameters before substitution.
