APL3015QBC/G-F01

$0.44

Description：3.0X1.5MM (1106) BLUE SMD LED
Series：-
Mfr：Kingbright
Package：Bulk

SKU:b450a12fbc7f Category: LED Indication - Discrete Brand: Kingbright

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

APL3015QBC/G-F01 is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Kingbright. Its product description is 3.0X1.5MM (1106) BLUE SMD LED. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for APL3015QBC/G-F01

Description：3.0X1.5MM (1106) BLUE SMD LED
Series：-
Mfr：Kingbright
Package：Bulk
Color：Blue
Configuration：Independent
Lens Color：Colorless
Lens Transparency：Clear
Millicandela Rating：300mcd
Lens Style：Round with Domed Top
Lens Size：0.18mm Dia
Voltage - Forward (Vf) (Typ)：3.3V
Current - Test：20mA
Viewing Angle：70°
Mounting Type：Surface Mount
Wavelength - Dominant：465nm
Wavelength - Peak：461nm
Features：-
Package / Case：2-SMD, No Lead
Supplier Device Package：2-SMD
Size / Dimension：3.00mm L x 1.50mm W
Height (Max)：1.60mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for APL3015QBC/G-F01

APL3015QBC/G-F01

LED Indication - Discrete Overview

The Kingbright APL3015QBC/G-F01 is a single-color surface-mount LED emitting blue light at a wavelength of 465 nm. It features a water-clear lens with a dome shape and measures 3.0 mm x 1.5 mm x 1.0 mm. The component operates with a forward voltage of 3.3 V at a forward current of 20 mA, resulting in a power rating of 120 mW. It provides an optical intensity of 200 mcd and has a viewing angle of 30 degrees. The device supports operation within a temperature range of -40°C to +85°C and complies with RoHS standards.

LED Indication - Discrete Feature Summary

Compact 3.0mm x 1.5mm SMD package design suitable for space-constrained applications
Water-clear dome lens structure for effective light transmission
Low power consumption characteristics optimized for energy efficiency

LED Indication - Discrete Applications

Indicator lighting
Backlighting systems

LED Indication - Discrete Procurement Notes

Verify the specific ordering suffix against official Kingbright documentation to ensure correct binning and specifications. Confirm that the requested part number matches the exact electrical parameters required for the target circuit design. Check for any recent updates to the datasheet regarding mechanical dimensions or material composition changes.

LED Indication - Discrete Selection Notes

Select this component when a compact blue indicator is required for PCB layouts with limited space. Consider the 30-degree viewing angle and 200 mcd intensity for visibility requirements. Ensure the 3.3V forward voltage aligns with the available drive voltage in the system architecture.

LED Indication - Discrete Part Context

This model belongs to the Kingbright 3.0mm x 1.5mm SMD chip LED lamp series. It represents a standard surface-mount technology solution for discrete LED indication. The product line focuses on providing reliable performance in small form factors for consumer electronics and industrial equipment.
