APSC100ELL391MHB5S

APSC100ELL391MHB5S is listed in the Aluminum - Polymer Capacitors range at ChipApex. The manufacturer field lists Chemi-Con. Its product description is CAP ALUM POLY 390UF 20% 10V TH. Review the specifications below when checking this part for your BOM.

Aluminum - Polymer Capacitors specifications for APSC100ELL391MHB5S

• Description：CAP ALUM POLY 390UF 20% 10V TH
• Series：NPCAP™-PSC
• Mfr：Chemi-Con
• Package：Bulk
• Type：Polymer
• Capacitance：390 µF
• Tolerance：±20%
• Voltage - Rated：10 V
• ESR (Equivalent Series Resistance)：9mOhm
• Lifetime @ Temp.：2000 Hrs @ 105°C
• Operating Temperature：-55°C ~ 105°C
• Ratings：-
• Applications：General Purpose
• Ripple Current @ High Frequency：5.65 A @ 100 kHz
• Lead Spacing：0.138" (3.50mm)
• Size / Dimension：0.315" Dia (8.00mm)
• Height - Seated (Max)：0.512" (13.00mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can
• Ripple Current @ Low Frequency：-
• Features：-
