APSL00130911470M00

$0.51

Description：INDUCTOR POWER
Series：APSL
Mfr：Pulse Electronics
Package：Tape & Reel (TR)

SKU:c24489f5e4bf Category: Fixed Inductors Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

APSL00130911470M00 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is INDUCTOR POWER. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for APSL00130911470M00

Description：INDUCTOR POWER
Series：APSL
Mfr：Pulse Electronics
Package：Tape & Reel (TR)
Type：Drum Core, Wirewound
Material - Core：Ferrite
Inductance：47 µH
Tolerance：±20%
Current Rating (Amps)：1.6 A
Current - Saturation (Isat)：3.8A
Shielding：Unshielded
DC Resistance (DCR)：100mOhm Max
Q @ Freq：-
Frequency - Self Resonant：8MHz
Ratings：AEC-Q200
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.510" L x 0.370" W (12.95mm x 9.40mm)
Height - Seated (Max)：0.450" (11.43mm)
Features：-

Fixed Inductors datasheet and documents for APSL00130911470M00

APSL00130911470M00

Fixed Inductors Overview

The APSL00130911470M00 is a surface-mount power inductor from Pulse Electronics, designed for automotive applications. It features a ferrite drum core with unshielded construction and standard SMD terminations. The component has an inductance of 47 µH with a 20% tolerance, tested at 1 kHz. It supports a maximum DC current of 1.6 A and operates within a temperature range of -40°C to +125°C. The package dimensions are 12.5 mm x 12.5 mm x 8 mm.

Fixed Inductors Feature Summary

Unshielded drum core wirewound design
Automotive-grade qualification
Ferrite core material

Fixed Inductors Applications

Automotive electronics
Power supply circuits
DC-DC converters

Fixed Inductors Procurement Notes

Verify the specific manufacturer datasheet for complete electrical characteristics and mechanical drawings. Confirm that the unshielded configuration meets electromagnetic interference requirements for the target application. Ensure compatibility with automated pick-and-place equipment due to the reel packaging format.

Fixed Inductors Selection Notes

Select this component when an unshielded inductor is required for cost-sensitive or space-constrained automotive designs. The 47 µH value and 1.6 A rating suit moderate power filtering needs. Consider thermal management capabilities given the 125°C maximum operating temperature limit.

Fixed Inductors Part Context

This part belongs to the APSL series of power inductors manufactured by Pulse Electronics. It utilizes a ferrite drum core structure typical for high-current applications. The series is specifically targeted at automotive markets requiring robust passive components.
