APT1608QWF/D

$0.41

Description：LED 1.6X0.8 WHITE SMD
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:03d1c7105b52 Category: LED Indication - Discrete Brand: Kingbright

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

APT1608QWF/D is listed in the LED Indication - Discrete range at ChipApex. The manufacturer field lists Kingbright. Its product description is LED 1.6X0.8 WHITE SMD. Review the specifications below when checking this part for your BOM.

LED Indication - Discrete specifications for APT1608QWF/D

Description：LED 1.6X0.8 WHITE SMD
Series：-
Mfr：Kingbright
Package：Tape & Reel (TR),Cut Tape (CT)
Color：White
Configuration：Standard
Lens Color：Yellow
Lens Transparency：-
Millicandela Rating：250mcd
Lens Style：Rectangle with Flat Top
Lens Size：1.20mm x 0.80mm
Voltage - Forward (Vf) (Typ)：3.3V
Current - Test：20mA
Viewing Angle：160°
Mounting Type：Surface Mount
Wavelength - Dominant：-
Wavelength - Peak：-
Features：-
Package / Case：0603 (1608 Metric)
Supplier Device Package：SMD
Size / Dimension：1.60mm L x 0.80mm W
Height (Max)：0.75mm
Grade：-
Qualification：-

LED Indication - Discrete datasheet and documents for APT1608QWF/D

APT1608QWF/D

LED Indication - Discrete Overview

The Kingbright APT1608QWF/D is a single-color surface-mount LED in a 0603 (1.6 x 0.8 mm) package. It emits ultra-white light with a peak wavelength of 470 nm and a dominant wavelength of 465 nm. The component features a water-clear rectangular lens with a 120-degree viewing angle. Electrical characteristics include a forward voltage of 3.3 V at a test current of 20 mA, with a power rating of 120 mW. It operates within a temperature range of -40°C to +85°C.

LED Indication - Discrete Feature Summary

Ultra-white illumination output for high color fidelity applications
Water-clear lens design for maximum light transmission efficiency
Compact 0603 footprint suitable for dense surface-mount layouts

LED Indication - Discrete Applications

Backlighting for portable electronic displays
Indicator lamps in consumer appliances
General-purpose lighting modules

LED Indication - Discrete Procurement Notes

Verify the specific suffix configuration against the manufacturer datasheet to ensure correct optical and electrical specifications. Confirm RoHS compliance status and moisture sensitivity level prior to assembly. Ensure ordering documentation matches the exact part number variant to avoid functional discrepancies in production.

LED Indication - Discrete Selection Notes

Select this component for designs requiring compact white-light sources with standard 0603 dimensions. Consider the 3.3 V forward voltage drop when designing drive circuits. Evaluate thermal management requirements based on the 120 mW power rating and operating temperature limits.

LED Indication - Discrete Part Context

This device belongs to the Kingbright APT1608 series of surface-mount LEDs. The series offers various color options in a standardized 1.6 x 0.8 mm package. The QWF/D designation specifically identifies the ultra-white color variant within this family.
