B7603-L

Antennas RF Overview

The TE Connectivity B7603-L is a mobile load coil antenna designed for the 760-870 MHz frequency band. It features a chrome whip construction with an NMO base mount configuration. The antenna provides a gain of 3 dB and operates at a center frequency of 815 MHz. It is engineered for vehicular applications requiring reliable RF transmission within the specified UHF range.

Antennas RF Feature Summary

• Mobile load coil design optimized for compact vehicular installations
• Chrome whip construction for environmental durability
• NMO base mount interface for secure vehicle attachment

Antennas RF Applications

• Vehicular communication systems
• Mobile radio installations
• UHF band signal transmission

Antennas RF Procurement Notes

Verify the exact part number B7603-L against official TE Connectivity documentation to ensure compatibility with specific vehicle mounting requirements. Confirm that the NMO base mount specification matches the intended installation hardware. Cross-reference the 760-870 MHz frequency range with operational needs to guarantee proper signal performance in the target environment.

Antennas RF Selection Notes

Select this model when a dedicated mobile load coil antenna is required for the 760-870 MHz spectrum. The NMO base mount ensures standardized integration with compatible vehicle fixtures. Consider the chrome finish for aesthetic consistency and corrosion resistance in outdoor vehicular environments where robust physical construction is necessary.

Antennas RF Part Context

This component belongs to the TE Connectivity antenna portfolio, specifically categorized as a mobile load coil antenna. It serves as a specialized RF solution for vehicular platforms operating in the UHF band. The product line focuses on providing reliable connectivity through mechanically robust designs suitable for mobile deployment scenarios.

Antennas RF Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
