B8965CNS

$72.47

Description：RF ANT 896MHZ WHIP STR NMO BASE
Series：-
Mfr：TE Connectivity
Package：Bulk

SKU:b17d7270c0cd Category: RF Antennas Brand: TE Connectivity

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

B8965CNS is listed in the Antennas RF range at ChipApex. The manufacturer field lists TE Connectivity. Its product description is RF ANT 896MHZ WHIP STR NMO BASE. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for B8965CNS

Description：RF ANT 896MHZ WHIP STR NMO BASE
Series：-
Mfr：TE Connectivity
Package：Bulk
RF Family/Standard：-
Frequency Group：UHF (300MHz ~ 1GHz)
Frequency (Center/Band)：896MHz
Frequency Range：896MHz ~ 970MHz
Antenna Type：Whip, Straight
Number of Bands：1
VSWR：-
Return Loss：-
Gain：5dBi
Features：-
Termination：NMO
Ingress Protection：IP67
Grade：-
Qualification：-
Mounting Type：Base Mount
Height (Max)：16.000" (406.40mm)
Applications：-
Power - Max：-

Antennas RF datasheet and documents for B8965CNS

B8965CNS

Antennas RF Overview

The TE Connectivity B8965CNS is a UHF whip antenna designed for operations between 896MHz and 970MHz, with a center frequency of 933MHz. It provides 5dBi peak gain and features an NMO base mount. The unit includes a 16-inch coil whip with a 10-inch radiating element. It is engineered for installations lacking a suitable ground plane and utilizes a loading coil with heavy-duty chrome plating.

Antennas RF Feature Summary

Engineered for ground-plane-free installations
Heavy-duty chrome-plated loading coil
Omnidirectional radiation pattern

Antennas RF Applications

Vehicular communications
Cellular network infrastructure
ISM band applications

Antennas RF Procurement Notes

Verify component authenticity through authorized TE Connectivity channels. Confirm the specific suffix 'CN' or 'CNS' matches project requirements, as variants may differ in packaging or minor specifications. Ensure compatibility with existing mounting hardware before finalizing procurement orders.

Antennas RF Selection Notes

Select this model when a compact UHF solution is required without a vehicle roof ground plane. The NMO base ensures secure attachment to metal surfaces. Consider the physical dimensions of the 16-inch coil against available space constraints during system integration planning.

Antennas RF Part Context

This component belongs to the TE Connectivity Laird mobile coil antenna family. It serves as a specialized external mount solution for UHF bands. The design prioritizes durability and performance in environments where traditional ground planes are unavailable or impractical.
