BKT-133-01-F-V-A

Headers, Male Pins Overview

The BKT-133-01-F-V-A is a surface mount header connector from the Samtec BKT series, featuring 33 positions in a dual-row configuration. It utilizes a 1.00 mm (0.039 inch) pitch with square male pins designed for board-to-board applications. The connector includes an integrated four-wall shielded shroud and employs a push-pull locking mechanism to secure mating connections. Contact surfaces are gold-plated over nickel with a thickness of 3.00 µin (0.076 µm), while the tail contacts are tin-plated. Constructed with phosphor bronze contacts and black liquid crystal polymer insulation rated UL94 V-0, it supports a current rating of 2.8A per contact and operates within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Integrated four-wall shielded shroud provides electromagnetic interference protection
• Push-pull locking mechanism ensures secure mating retention
• Surface mount termination facilitates automated PCB assembly
• Gold-plated contact surfaces ensure reliable signal transmission

Headers, Male Pins Applications

• Board-to-board interconnections requiring shielding
• High-density electronic modules
• Industrial control systems
• Telecommunications equipment

Headers, Male Pins Procurement Notes

Verify that the suffix 'A' corresponds to the specific packaging or variant requirements for your production line. Confirm that the surface mount footprint matches the design layout. Ensure compatibility with mating connectors from the BKS series. Check RoHS compliance status if required by regional regulations. Validate the operating temperature range against environmental conditions.

Headers, Male Pins Selection Notes

Select this component when board-to-board connectivity requires both high density and electromagnetic shielding. The 1.00 mm pitch allows for compact designs compared to standard 2.54 mm headers. The push-pull feature simplifies assembly and disassembly processes. Consider the stack height and insulation material properties for thermal management. Ensure the current rating meets the circuit load requirements.

Headers, Male Pins Part Context

This part belongs to the BKT series of micro headers from Samtec Inc., designed for space-constrained applications. The series offers various stacking heights and shielding options. The BKT-133-01-F-V-A specifically denotes a 33-position, shielded, surface mount variant. It complements the BKS series sockets for complete interconnect solutions. The product is actively manufactured and supported by official documentation.
