CTCDEP147HF-R30N

Fixed Inductors Overview

The CTCDEP147HF-R30N is a surface-mount shielded power inductor from Central Technologies. It features a nominal inductance of 0.3 µH with a ±20% tolerance. The component operates within a temperature range of -30°C to 100°C and is tested at 100 kHz. It utilizes a nonstandard package with dimensions of 0.591 inches.

Fixed Inductors Feature Summary

• Shielded construction for magnetic field containment
• Surface mount mounting type for automated assembly
• Designed for power application environments

Fixed Inductors Applications

• DSP controller motor control applications
• Real-time system stability circuits
• Power supply filtering

Fixed Inductors Procurement Notes

Verify the specific suffix 'R30N' against official Central Technologies documentation to confirm the exact inductance value and tolerance. Ensure the operating temperature range of -30°C to 100°C meets the environmental requirements of the target design. Confirm RoHS compliance status through the manufacturer's current datasheet, as regulatory status can vary by production batch.

Fixed Inductors Selection Notes

Select this component when a low-inductance, high-current shielded solution is required for surface-mount processes. The 0.591-inch form factor must be accommodated within the PCB layout constraints. Consider the 100 kHz test frequency for impedance matching in switching power supplies. Verify that the thermal performance supports the intended duty cycle without exceeding the 100°C upper limit.

Fixed Inductors Part Context

This part belongs to the CTCDEP147HF series of fixed inductors manufactured by Central Technologies. The series includes various values such as R10, R30, and higher microhenry ratings. These components are generally used in electronic systems requiring reliable magnetic components for power management and signal integrity tasks.

Fixed Inductors Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material. Cross-referencing requires consulting the manufacturer's official replacement guide or equivalent electrical parameter sheets.
