DASUTCC500MD

$97.25

Description：RF ANT 700MHZ/850MHZ FLAT PATCH
Series：Clarity™
Mfr：Pulse Electronics
Package：Bulk

SKU:bd7a89cc2c16 Category: RF Antennas Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

DASUTCC500MD is listed in the Antennas RF range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is RF ANT 700MHZ/850MHZ FLAT PATCH. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for DASUTCC500MD

Description：RF ANT 700MHZ/850MHZ FLAT PATCH
Series：Clarity™
Mfr：Pulse Electronics
Package：Bulk
RF Family/Standard：Cellular, WiFi
Frequency Group：Wide Band
Frequency (Center/Band)：700MHz, 850MHz, 900MHz, 1.8GHz, 1.9GHz, 2.1GHz, 2.4GHz, 2.6GHz
Frequency Range：608MHz ~ 960MHz, 1.695GHz ~ 2.2GHz, 2.3GHz ~ 2.7GHz
Antenna Type：Flat Patch
Number of Bands：3
VSWR：2
Return Loss：-
Gain：7dBi, 7dBi, 5dBi
Features：Cable - 500mm
Termination：Mini-DIN Female
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Panel Mount
Height (Max)：0.331" (8.40mm)
Applications：LTE, Wi-Fi
Power - Max：40 W

Antennas RF datasheet and documents for DASUTCC500MD

DASUTCC500MD

Antennas RF Overview

The DASUTCC500MD is a flat patch RF antenna from the Clarity series by Pulse Electronics, designed for distributed antenna systems. It operates across three frequency bands: 608MHz to 960MHz, 1.695GHz to 2.2GHz, and 2.3GHz to 2.7GHz. The unit features a 500mm cable with a Mini-DIN female connector for panel installation. It provides gains of 4dBi and 6dBi with a maximum VSWR of 2 and supports up to 40W power. The antenna height is 8.40mm.

Antennas RF Feature Summary

Ultra-thin design with industry-leading PIM rating of -155dBc at 2x20 watts
Flat patch construction for nearly invisible aesthetic integration
Multi-band operation supporting Wi-Fi and cellular frequencies

Antennas RF Applications

In-building distributed antenna systems
Outdoor DAS installations
Wi-Fi network infrastructure

Antennas RF Procurement Notes

Verify component status as this part is marked as obsolete. Confirm availability through authorized distributors or secondary markets. Ensure compatibility with existing Mini-DIN connectors and mounting requirements. Check for valid replacement alternatives within the same product family if new procurement is required.

Antennas RF Selection Notes

Select this model for applications requiring low-profile antennas with high linearity. Consider the specific frequency bands and gain requirements against system needs. Verify connector type and cable length suitability for the installation environment. Evaluate the ultra-thin profile benefits for aesthetic-sensitive locations.

Antennas RF Part Context

This component belongs to the DAS Ultra-Thin Clear Ceiling Antennas family. It is engineered for seamless integration into building structures while maintaining high RF performance. The series emphasizes minimal visual impact alongside robust signal distribution capabilities for modern wireless networks.
