Pushbutton Switches E221SD1AV2GE product image

E221SD1AV2GE

Description：SWITCH PUSHBUTTON DPDT 1A 120V
Series：E020
Mfr：C&K
Package：Tray

SKU:09cbf25a0ec7 Category: Pushbutton Switches Brand: C&K

ChipApex WhatsApp

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

E221SD1AV2GE is listed in the Pushbutton Switches range at ChipApex. The manufacturer field lists C&K. Its product description is SWITCH PUSHBUTTON DPDT 1A 120V. Review the specifications below when checking this part for your BOM.

Pushbutton Switches specifications for E221SD1AV2GE

Description：SWITCH PUSHBUTTON DPDT 1A 120V
Series：E020
Mfr：C&K
Package：Tray
Mounting Type：Through Hole, Right Angle, Vertical
Type：Standard
Circuit：DPDT
Switch Function：On-Mom
Current Rating (Amps)：1A (AC/DC)
Actuator Type：Round, Plunger
Actuator Marking：No Marking
Color - Actuator/Cap：White
Illumination Type, Color：-
Illumination Voltage (Nominal)：-
Termination Style：PC Pin
Ingress Protection：-
Features：Process Sealed
Panel Cutout Dimensions：-
Operating Temperature：-30°C ~ 75°C
Voltage Rating - DC：28 V
Voltage Rating - AC：120 V

Pushbutton Switches datasheet and documents for E221SD1AV2GE
