ECW-F2W824JA

ECW-F2W824JA is listed in the Film Capacitors range at ChipApex. The manufacturer field lists Panasonic Electronic Components. Its product description is CAP FILM 0.82UF 5% 450VDC RADIAL. Review the specifications below when checking this part for your BOM.

Film Capacitors specifications for ECW-F2W824JA

• Description：CAP FILM 0.82UF 5% 450VDC RADIAL
• Series：ECW-F(A)
• Mfr：Panasonic Electronic Components
• Package：Bulk
• Capacitance：0.82 µF
• Tolerance：±5%
• Voltage Rating - AC：84V
• Voltage Rating - DC：450V
• Dielectric Material：Polypropylene (PP), Metallized
• Operating Temperature：-40°C ~ 105°C
• Mounting Type：Through Hole
• Package / Case：Radial
• Size / Dimension：0.713" L x 0.323" W (18.10mm x 8.20mm)
• Height - Seated (Max)：0.559" (14.20mm)
• Termination：PC Pins
• Lead Spacing：0.591" (15.00mm)
• Applications：High Frequency, Switching
• Ratings：-
• Features：-
