EHT-108-01-F-D-SR

Headers, Male Pins Overview

The EHT-108-01-F-D-SR is a 2.00 mm pitch shrouded IDC ejector header manufactured by Samtec. It features 16 positions arranged in a dual row configuration with a 2 mm row spacing. The connector utilizes surface mount termination and straight pin orientation. Contact plating consists of gold over nickel for mating surfaces and tin over nickel for soldering. Constructed from phosphor bronze contacts and black liquid crystal polymer insulation, it operates within a temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

• Integrates an ejector latch mechanism for secure cable retention and simplified removal
• Features a shrouded design with polarization notches to ensure correct mating alignment
• Supports surface mount installation with straight pin configuration for board-to-cable connections

Headers, Male Pins Applications

• Board-to-cable interconnect systems requiring IDC termination
• Applications utilizing TCSD series mating connectors
• Electronic assemblies needing polarized high-density signal routing

Headers, Male Pins Procurement Notes

Verify the specific suffix 'SR' against official Samtec documentation to confirm right-angle or specific variant characteristics, as standard 'SM' denotes surface mount. Confirm RoHS compliance status and material declarations via the manufacturer's latest datasheet. Ensure mating components match the 2.00 mm pitch and shrouded geometry requirements for reliable mechanical and electrical performance.

Headers, Male Pins Selection Notes

Select this component when a shrouded, polarized IDC header with an ejector feature is required for 16-position applications. The 2.00 mm pitch suits dense board layouts. Verify that the mating cable assembly corresponds to the TCSD series or compatible .020 inch square post terminals. Ensure the operating environment falls within the specified -55°C to +125°C range and that surface mount processing capabilities are available.

Headers, Male Pins Part Context

This part belongs to the EHT series of 2.00 mm pitch shrouded IDC ejector headers. The series offers various mounting styles and pin counts. The EHT-108-01-F-D-SR specifically provides a 16-position dual-row configuration. It is designed for robust board-to-cable connections using IDC technology, often paired with TCSD socket assemblies for complete interconnect solutions.

Headers, Male Pins Replacement Considerations

Compatible mating connectors include the TCSD series IDC sockets. Direct replacement parts within the same family require matching the 16-position count, 2.00 mm pitch, and dual-row layout. Verify that any substitute maintains the shrouded and ejector latch functionality to preserve alignment and retention characteristics.
