EHT-117-01-S-D-25

Headers, Male Pins Overview

The EHT-117-01-S-D-25 is a surface-mount header connector from Samtec's EHT series. It features a 2.00mm pitch, 34 positions arranged in two rows, and shrouded four-wall construction. The contacts are gold-plated phosphor bronze with a mating length of 3.05mm. Designed for board-to-cable or wire applications, it operates within a temperature range of -55°C to 125°C and carries an UL94 V-0 flammability rating.

Headers, Male Pins Feature Summary

• Shrouded four-wall design provides polarized position protection
• Surface-mount termination ensures secure PCB attachment
• Gold-plated contacts offer reliable conductivity

Headers, Male Pins Applications

• Board-to-board interconnects
• Wire-to-board connections
• Electronic module assembly

Headers, Male Pins Procurement Notes

Verify the specific suffix '25' against official Samtec documentation to confirm exact dimensional tolerances and packaging specifications. Ensure compatibility with mating connectors regarding height and pin configuration before procurement.

Headers, Male Pins Selection Notes

Select this component for applications requiring high-density connections with polarized positioning. The surface-mount style suits automated assembly processes, while the shrouded design prevents misalignment during mating.

Headers, Male Pins Part Context

This part belongs to the EHT series of ejector headers, designed for robust connectivity. It shares the 2.00mm pitch family characteristics but differs in termination type and row count compared to other variants like TMMH.

Headers, Male Pins Replacement Considerations

EHT-117-01-S-D-RA is a right-angle alternative within the same series.
