F1199DD30

Power Line Filter Modules Overview

The Curtis Industries F1199DD30 is a single-phase EMC/EMI line filter designed for chassis mounting. It supports a rated current of 30 A at 250 VAC and operates at 50/60 Hz frequencies. The unit features a single-stage configuration with threaded post termination (8-32). This component is certified by CE, CSA, TUV, and UR, ensuring compliance with international safety standards for power line filtering applications.

Power Line Filter Modules Feature Summary

• Provides electromagnetic interference suppression through single-stage filtration
• Utilizes threaded post termination for secure mechanical and electrical connection
• Designed for direct chassis mounting to facilitate integration into equipment enclosures

Power Line Filter Modules Applications

• High-power motor control cabinets
• Industrial machinery power entry points
• Equipment requiring EMI/RFI noise reduction on AC lines

Power Line Filter Modules Procurement Notes

Verify the specific termination style matches the design requirements, as this model uses threaded posts rather than quick-connect terminals found in other series. Confirm that the chassis mounting holes align with the enclosure layout. Ensure the operating environment temperature remains within the specified limits for the polypropylene insulation material used in the housing.

Power Line Filter Modules Selection Notes

Select this model when a high current capacity of 30 A is required alongside single-stage filtering performance. The threaded post interface is suitable for applications where robust mechanical connections are prioritized over rapid assembly. Compare against the F1199BB10 if lower current ratings or different termination styles are acceptable for the specific system design constraints.

Power Line Filter Modules Part Context

This component belongs to the F1199 series of general-purpose single-phase filters from Curtis Industries. The series offers various current ratings and termination options to accommodate diverse power entry module designs. The F1199DD30 specifically addresses high-current needs within this family, providing a standardized solution for industrial power filtering.

Power Line Filter Modules Replacement Considerations

Publicly confirmed substitute part numbers were not identified in the provided source data. Verify compatibility with existing mounting hardware and terminal interfaces before considering alternative manufacturers.
