F8824SCSS

Overview

The F8824SCSS is a Type 4X angled wiring trough manufactured by nVent Hoffman. Constructed from 14-gauge 304 stainless steel with a No. 2B finish, it measures 24 inches in length, 8 inches in width, and 9-1/2 inches in height. The unit features continuously welded and ground smooth seams for durability. It includes an oil-resistant gasket and adhesive to ensure environmental sealing. The cover is secured via threaded screws that are captivated into the body.

Feature Summary

• Constructed from 14-gauge 304 stainless steel with a No. 2B finish
• Features continuously welded and ground smooth seams
• Includes oil-resistant gasket and adhesive for sealing
• Utilizes captivated stainless steel cover screws

Applications

• Outdoor industrial wiring management
• Indoor hazardous area cable routing
• Chemical processing plant infrastructure
• Marine environment wire protection

Procurement Notes

Verify the specific model suffix against official nVent Hoffman documentation to confirm material grade and dimensional accuracy. Ensure compatibility with existing enclosure systems regarding mounting requirements. Confirm that the Type 4X rating meets the specific environmental exposure criteria of the installation site. Cross-reference the captive screw mechanism with maintenance access protocols.

Selection Notes

Select this component when high corrosion resistance is required for both indoor and outdoor applications. The 304 stainless steel construction provides robust protection against harsh chemicals and moisture. The angled design facilitates efficient cable routing in confined spaces. Verify that the 14-gauge thickness meets structural load requirements for the intended installation environment.

Part Context

This part belongs to the F24 Series of angled wiring troughs from nVent Hoffman. These units are designed for use as wireways or gutters within larger electrical enclosure assemblies. They complement other Hoffman products such as the A722418SSFSN4 enclosure and HF series fans. The series emphasizes durable construction for demanding industrial settings.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
