FTM-110-02-FM-DV-TR

$1.43

Description：CONN HEADER SMD 20POS 1MM
Series：FTM
Mfr：Samtec Inc.
Package：Tape & Reel (TR)

SKU:55a6d1375a53 Category: Headers, Male Pins Brand: Samtec Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

FTM-110-02-FM-DV-TR is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Samtec Inc.. Its product description is CONN HEADER SMD 20POS 1MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for FTM-110-02-FM-DV-TR

Description：CONN HEADER SMD 20POS 1MM
Series：FTM
Mfr：Samtec Inc.
Package：Tape & Reel (TR)
Connector Type：Header, Cuttable
Contact Type：Male Pin
Pitch - Mating：0.039" (1.00mm)
Number of Positions：20
Number of Rows：2
Row Spacing - Mating：0.039" (1.00mm)
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.075" (1.90mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.038" (0.97mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：Flash
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Liquid Crystal Polymer (LCP)
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：-
Insulation Color：Black
Current Rating (Amps)：2.8A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for FTM-110-02-FM-DV-TR

FTM-110-02-FM-DV-TR

Headers, Male Pins Overview

The FTM-110-02-FM-DV-TR is a 1.00 mm surface mount micro low profile terminal strip manufactured by Samtec. It features a 20-position, 2-row configuration with a straight solder termination designed for SMD installation. The connector utilizes gold-plated phosphor bronze contacts and an LCP insulator, rated for 350 V voltage and 3.2 A current per contact. It supports data rates up to 8 Gbps and operates within a temperature range of -55°C to +125°C.

Headers, Male Pins Feature Summary

Micro low profile header design optimized for space-constrained applications
Flexible positioning capabilities allowing up to 100 I/Os
Available with optional end shrouds and guide posts for alignment

Headers, Male Pins Applications

High-density board-to-board interconnects
Mezzanine connections in compact electronic modules
Surface mount assembly requiring low-profile stacking

Headers, Male Pins Procurement Notes

Verify the specific suffix 'TR' indicates tape-and-reel packaging when ordering. Confirm that the 'DV' designation aligns with the required vertical orientation and shroud configuration for your PCB layout. Ensure compatibility with the mating component's pin height and plating specifications before finalizing procurement.

Headers, Male Pins Selection Notes

Select this component for applications demanding a 1.00 mm pitch with surface mount reliability. Consider the flexible position options if custom I/O counts are required. Verify that the 8 Gbps data rate capability meets the signal integrity requirements of the target application environment.

Headers, Male Pins Part Context

This part belongs to the FTM series of 1.00 mm surface mount micro terminal strips. It is characterized by its low profile and flexible positioning options. The series is designed to mate with corresponding sockets or headers in high-density interconnect scenarios.
