GTX-2200-Y22

$27.74

Description：LINE FLTR 560VDC 250VAC 20A CHAS
Series：GTX
Mfr：KEMET
Package：Box

SKU:e6a904140d63 Category: Power Line Filter Modules Brand: KEMET

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

GTX-2200-Y22 is listed in the Power Line Filter Modules range at ChipApex. The manufacturer field lists KEMET. Its product description is LINE FLTR 560VDC 250VAC 20A CHAS. Review the specifications below when checking this part for your BOM.

Power Line Filter Modules specifications for GTX-2200-Y22

Description：LINE FLTR 560VDC 250VAC 20A CHAS
Series：GTX
Mfr：KEMET
Package：Box
Filter Type：Single Phase
Configuration：Single Stage
Voltage - Rated DC：560V
Voltage - Rated AC：250V
Current：20 A
Frequency - Operating：50/60Hz
Applications：General Purpose
Approval Agency：cUL, TUV, UL
Operating Temperature：-25°C ~ 55°C
Mounting Type：Chassis Mount
Termination Style：Terminal Block
Inductance：-
Voltage - Rated AC (Phase to Ground/Neutral)：-
Voltage - Rated AC (Phase to Phase)：-

Power Line Filter Modules datasheet and documents for GTX-2200-Y22

GTX-2200-Y22

Power Line Filter Modules Overview

The KEMET GTX-2200-Y22 is a single-phase EMI/RFI power line filter designed for chassis mounting with screw terminals. It supports a voltage rating of 250 VAC and 560 VDC, handling a current rating of 20 A at an operating frequency of 60 Hz. The unit features a capacitance of 2200 pF and an inductance of 300 µH. Physical dimensions are 75 mm in length, 44 mm in width, and 25 mm in height. It operates within a temperature range of -25°C to +55°C and has a leakage current of 500 uA.

Power Line Filter Modules Feature Summary

Provides electromagnetic interference suppression for single-phase AC power lines
Utilizes screw terminal connections for secure chassis mounting
Complies with UL, cUL, and TUV safety standards

Power Line Filter Modules Applications

General purpose power line filtering
Industrial equipment power conditioning
Electronic systems requiring EMI/RFI noise reduction

Power Line Filter Modules Procurement Notes

Verify the specific suffix code against official KEMET documentation to confirm exact electrical characteristics and compliance certifications. Ensure the ordering part number matches the required voltage and current ratings for the target application. Confirm mechanical mounting requirements align with the chassis mount design and screw terminal specifications provided in the datasheet.

Power Line Filter Modules Selection Notes

Select this component for applications requiring single-phase EMI filtering with a 20 A current capacity. Verify that the 250 VAC / 560 VDC voltage ratings meet system requirements. Consider the physical dimensions and chassis mount style for enclosure integration. Ensure the operating temperature range suits the environmental conditions.

Power Line Filter Modules Part Context

This component belongs to the KEMET GTX Single-Phase series of power line filters. These filters are engineered for general-purpose EMI/RFI suppression in AC power circuits. The series offers various configurations to accommodate different current and voltage requirements while maintaining compact form factors suitable for industrial and commercial electronic equipment.
