ISE1215A-TR

ISE1215A-TR is listed in the DC DC Converters range at ChipApex. The manufacturer field lists XP Power. Its product description is DC DC CONVERTER 15V 1W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for ISE1215A-TR

• Description：DC DC CONVERTER 15V 1W
• Series：ISE (1W)
• Mfr：XP Power
• Package：Tape & Reel (TR),Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：10.8V
• Voltage - Input (Max)：13.2V
• Voltage - Output 1：15V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：67mA
• Power (Watts)：1 W
• Voltage - Isolation：1.5 kV
• Applications：ITE (Commercial)
• Features：SCP
• Operating Temperature：-40°C ~ 105°C
• Efficiency：81%
• Mounting Type：Surface Mount
• Package / Case：8-SMD Module, 5 Leads
• Size / Dimension：0.50" L x 0.33" W x 0.28" H (12.7mm x 8.3mm x 7.0mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：61000
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for ISE1215A-TR
