IXD2142A33CER-G

$0.46

Description：IC REG BOOST 3.3V 800MA 6USPC
Series：-
Mfr：Zilog
Package：Tape & Reel (TR)

SKU:c92303d0d22f Category: Voltage Regulators - DC DC Switching Regulators Brand: Zilog

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

IXD2142A33CER-G is listed in the Voltage Regulators - DC DC Switching Regulators range at ChipApex. The manufacturer field lists Zilog. Its product description is IC REG BOOST 3.3V 800MA 6USPC. Review the specifications below when checking this part for your BOM.

Voltage Regulators - DC DC Switching Regulators specifications for IXD2142A33CER-G

Description：IC REG BOOST 3.3V 800MA 6USPC
Series：-
Mfr：Zilog
Package：Tape & Reel (TR)
Function：Step-Up
Output Configuration：Positive
Topology：Boost
Output Type：Fixed
Number of Outputs：1
Voltage - Input (Min)：0.65V
Voltage - Input (Max)：6V
Voltage - Output (Min/Fixed)：3.3V
Voltage - Output (Max)：-
Current - Output：800mA
Frequency - Switching：1.2MHz
Synchronous Rectifier：Yes
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：6-UFDFN Exposed Pad
Supplier Device Package：6-USPC (1.8x2)
Grade：-
Qualification：-

Voltage Regulators - DC DC Switching Regulators datasheet and documents for IXD2142A33CER-G

IXD2142A33CER-G

Voltage Regulators - DC DC Switching Regulators Overview

The IXD2142A33CER-G is a switching voltage regulator manufactured by Zilog, classified under PMIC - Power Management ICs. It functions as a step-up DCDC converter with a load disconnect feature. The device supports an output current of 0.8A and operates at a switching frequency of 1.2MHz. It utilizes PFM/PWM auto-switching technology for efficiency optimization. The component is packaged in a reel format.

Voltage Regulators - DC DC Switching Regulators Feature Summary

Integrates a load disconnection function for system power management
Supports automatic switching between PFM and PWM modes
Provides step-up DCDC conversion capability

Voltage Regulators - DC DC Switching Regulators Applications

Portable electronic devices requiring efficient power regulation
Battery-powered systems utilizing step-up conversion
Applications necessitating load disconnection control

Voltage Regulators - DC DC Switching Regulators Procurement Notes

Verify the complete part number including suffixes against official Zilog documentation to ensure correct functionality and package type. Confirm availability status through authorized distributors as supply may be restricted. Cross-reference datasheet specifications with design requirements before integration.

Voltage Regulators - DC DC Switching Regulators Selection Notes

Select this component when a 0.8A step-up converter with integrated load disconnect is required. Ensure the 1.2MHz switching frequency aligns with EMI constraints. Verify that PFM/PWM auto-switching meets efficiency targets for the specific application load profile.

Voltage Regulators - DC DC Switching Regulators Part Context

This part belongs to the Zilog IXD series of power management ICs. It is distinct from similar models like IXD2141 which may lack PFM/PWM auto-switching or have different frequency characteristics. The 'A' suffix typically denotes specific electrical variations within the family.

Voltage Regulators - DC DC Switching Regulators Replacement Considerations

Check for direct substitutes such as IXD2142B33CER-G or IXD2142A33DMR-G. Verify pin compatibility and electrical parameter equivalence before substitution.
