LN840RPX

LED Indication - Discrete Overview

The Panasonic LN840RPX is a radial through-hole LED indicator featuring an orange lens with a flat-top design. It operates at a peak wavelength of 630nm and has a forward voltage of 2.1V. The component provides a luminous intensity of 4.5 mcd. It utilizes a round lens shape with dimensions of 4.4 mm. The maximum operating temperature is +85°C. This part belongs to the standard LEDs product line.

LED Indication - Discrete Feature Summary

• Round lens shape with flat-top design for visual indication
• Orange color output at 630nm peak wavelength
• Radial through-hole mounting configuration

LED Indication - Discrete Applications

• Panel status indicators
• Power supply status lights
• Equipment operational signaling

LED Indication - Discrete Procurement Notes

Verify component authenticity by checking manufacturer markings against official datasheets. Confirm package type matches radial through-hole requirements. Ensure environmental conditions align with the specified temperature range. Validate electrical parameters match circuit design needs before integration.

LED Indication - Discrete Selection Notes

Consider the specific optical requirements such as wavelength and intensity when selecting this component. Evaluate the physical dimensions to ensure compatibility with panel cutouts. Check the forward voltage drop to confirm suitability with the driving circuitry. Assess the thermal performance limits for the intended application environment.

LED Indication - Discrete Part Context

This LED belongs to Panasonic's round type series, designed for general-purpose indication. It offers a compact form factor suitable for various electronic devices. The radial lead configuration facilitates easy insertion into printed circuit boards. The orange color provides high visibility for status monitoring purposes.
