M22-2410446

Headers, Male Pins Overview

The M22-2410446 is a rectangular pin header from the Harwin M22 series, featuring an 8+8 position configuration (16 total) with a 2 mm pitch. It utilizes a right-angle through-hole solder termination and includes a push-pull fastening system for secure mating cycles. The contacts are tin-plated phosphor bronze, rated for 1 A current and 500 VAC voltage. The black nylon housing operates within a temperature range of -40°C to +105°C.

Headers, Male Pins Feature Summary

• Incorporates a push-pull fastening mechanism designed for repeated connect and disconnect operations typical in development environments.
• Features right-angle through-hole solder pins for reliable PCB mounting and board-to-board connectivity.
• Utilizes tin-plated phosphor bronze contacts housed in a UL94V-0 rated black nylon shell.

Headers, Male Pins Applications

• Development boards requiring frequent module swapping
• Modular electronic equipment interfaces
• Board-to-board interconnects in embedded systems

Headers, Male Pins Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm RoHS compliance status and specific lot traceability upon receipt. Ensure storage conditions maintain contact integrity prior to assembly. Cross-reference datasheet specifications against design requirements to validate electrical and mechanical suitability for the target application environment.

Headers, Male Pins Selection Notes

Select this part for applications demanding high durability through repeated mating cycles due to its integrated push-pull locking feature. The right-angle orientation facilitates compact board stacking. Verify that the 2 mm pitch and 16-position count align with circuit density needs. Consider the tin plating for cost-effective conductivity versus gold options if corrosion resistance requirements are moderate.

Headers, Male Pins Part Context

Part of the M22 series, which serves as a standard connector for embedded PCs, motherboards, and large electronic systems. The series offers various row configurations and contact counts, balancing high PCB density with height restrictions. It supports both SMT and through-hole variants across single and double-row layouts.

Headers, Male Pins Replacement Considerations

M22-2410442 is a documented substitute variant within the same series, sharing identical physical dimensions and pin configuration but differing in contact plating finish.

Headers, Male Pins FAQ

What type of fastening system does the M22-2410446 utilize?

It employs a push-pull fastening system designed to withstand repeated connect and disconnect cycles common in modular setups.

Is the M22-2410446 available in a surface-mount version?

No, this specific part number is configured for right-angle through-hole solder termination.
