M22-2540346

Headers, Male Pins Overview

The M22-2540346 is a male pin header connector from the Harwin M22 series, designed for board-to-board applications. It features a 2 mm pitch and a 6-position configuration arranged in a single row. The component utilizes a right-angle orientation with through-hole termination for secure PCB mounting. Contact surfaces are gold-plated to ensure reliable signal transmission. The housing is constructed from nylon, providing mechanical stability and electrical insulation.

Headers, Male Pins Feature Summary

• Right-angle design facilitates compact vertical integration on printed circuit boards
• Gold-plated contacts provide durable connection interfaces for signal integrity
• Single-row configuration supports streamlined routing within constrained spaces

Headers, Male Pins Applications

• Industrial control systems requiring robust interconnects
• Data collection equipment with space-constrained layouts
• Mobile maintenance devices needing reliable signal paths

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer datasheet to confirm contact plating thickness and material specifications. Ensure the selected variant matches the required right-angle orientation and through-hole termination style for your assembly process. Cross-reference the position count to prevent mismatching during procurement.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle male header is required for high-density connections. The 2 mm pitch allows for moderate spacing between adjacent circuits. Consider the single-row layout for simplified routing compared to dual-row alternatives. Verify that the nylon housing meets the thermal requirements of the soldering process.

Headers, Male Pins Part Context

This part belongs to the M22 series, a family of connectors known for industrial durability. The series offers various configurations including shrouded and unshrouded options. The M22-2540346 specifically addresses needs for angled insertion where vertical clearance is limited but horizontal space is available.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 2 mm pitch, 6-position count, and right-angle through-hole format. Verify compatibility with existing PCB footprints before replacing. Generic headers may lack the specific gold plating or nylon grade specified by Harwin.
