M252512FV

$64.86

Description：MODULE POWER 25A 600V SCR DIODE
Series：-

SKU:0d6a7504b598 Category: SCRs - Modules Brand: Sensata-Crydom

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

M252512FV is listed in the SCRs - Modules range at ChipApex. The manufacturer field lists Sensata-Crydom. Its product description is MODULE POWER 25A 600V SCR DIODE. Review the specifications below when checking this part for your BOM.

SCRs - Modules specifications for M252512FV

Description：MODULE POWER 25A 600V SCR DIODE
Series：-
Mfr：Sensata-Crydom
Package：Bulk
Structure：Bridge, Single Phase - SCRs/Diodes (Layout 1)
Number of SCRs, Diodes：2 SCRs, 2 Diodes
Voltage - Off State：600 V
Current - On State (It (AV)) (Max)：-
Current - On State (It (RMS)) (Max)：-
Current - Non Rep. Surge 50, 60Hz (Itsm)：300A @ 60Hz
Operating Temperature：-
Mounting Type：Chassis Mount
Package / Case：Module
Voltage - Gate Trigger (Vgt) (Max)：2.5 V
Current - Gate Trigger (Igt) (Max)：50 mA
Current - Hold (Ih) (Max)：75 mA
Grade：-
Qualification：-

SCRs - Modules datasheet and documents for M252512FV

M252512FV

SCRs - Modules Overview

The M252512FV is a single-phase SCR/diode bridge module manufactured by Sensata-Crydom. It features a chassis mount configuration with a 600V repetitive peak off-state voltage and a 25A average on-state current rating. The device utilizes silicon technology and includes two SCRs and two diodes in Layout 1. It provides 2500VAC RMS terminal-to-base isolation and operates within a standard junction temperature range.

SCRs - Modules Feature Summary

Single-phase SCR/diode bridge configuration for power control
Chassis mount design for secure mechanical installation
High voltage isolation between terminals and base

SCRs - Modules Applications

Thyristor switching circuits
Industrial power control systems
Motor speed control applications

SCRs - Modules Procurement Notes

Verify the specific suffix 'FV' against official datasheets to confirm pinout and mounting hole specifications. Ensure thermal management solutions match the 25A current rating. Confirm RoHS compliance status through the manufacturer's latest documentation before integration into regulated equipment designs.

SCRs - Modules Selection Notes

Select this module when a single-phase bridge rectifier or phase control arrangement is required. Compare the 600V voltage rating against circuit peak voltages. Evaluate the 25A current capacity against load requirements. Consider chassis mounting constraints versus PCB options available in the M25 series.

SCRs - Modules Part Context

This component belongs to the Crydom M25 Series of power SCR/diode modules. The series offers multiple circuit configurations and current ratings. It is designed for robust industrial environments requiring reliable thyristor switching capabilities with standardized mounting interfaces.

SCRs - Modules Replacement Considerations

Consult official substitution guides for equivalent voltage and current ratings. Verify pin compatibility and thermal characteristics when replacing with other single-phase SCR bridge modules from Sensata-Crydom or third-party manufacturers.
