M50-3202445

Headers, Receptacles, Female Sockets Overview

The Harwin M50-3202445 is a board-to-board connector receptacle from the Archer M50 series. It features a dual-row configuration with 24 positions (12+12) and a 1.27 mm pitch. The component utilizes surface-mount technology for installation and employs gold-plated contacts to ensure reliable signal transmission. Designed for vertical mating, it provides a compact interconnection solution suitable for high-density PCB layouts.

Headers, Receptacles, Female Sockets Feature Summary

• Dual-row socket assembly designed for vertical board-to-board mating applications
• Surface-mount termination method facilitates automated placement on printed circuit boards
• Gold-plated contact surfaces provide durable electrical connections with corrosion resistance

Headers, Receptacles, Female Sockets Applications

• Compact electronic device interconnections requiring high density
• Industrial control systems utilizing modular PCB architectures
• Telecommunications equipment needing reliable signal pathways

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific part number against official manufacturer documentation to confirm current production status and availability. Ensure that the selected variant matches the required row count and pitch specifications for your design. Cross-reference datasheets to validate compliance with relevant environmental standards before finalizing procurement decisions.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a dual-row, surface-mount receptacle with a 1.27 mm pitch is required. Consider the vertical mating orientation and gold plating for durability. Evaluate space constraints on the PCB to ensure the footprint accommodates the dual-row layout without interfering with adjacent components or assembly processes.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Harwin Archer M50 series, which specializes in high-density board-to-board interconnects. The series offers various configurations including single and dual rows with different pin counts. These connectors are engineered for applications demanding robust performance in compact spaces, supporting both through-hole and surface-mount technologies across the product line.

Headers, Receptacles, Female Sockets Replacement Considerations

Consult official Harwin documentation for verified substitute part numbers within the M50 series. Ensure any replacement maintains identical pitch, row configuration, and mounting style. Verify compatibility with existing mating headers before implementation.
