M50-3532042

Headers, Male Pins Overview

The M50-3532042 is a rectangular connector housing manufactured by Harwin Inc. It belongs to the M50 series, designed for high-density interconnect applications. This specific component is a plug housing with 42 positions, arranged in a 7-row configuration. It features a 1.27mm pitch between contacts, ensuring compact board space utilization. The housing is constructed from polyphenylene sulfide (PPS) material, providing robust thermal stability and mechanical strength. It supports surface mount technology (SMT) termination for automated assembly processes.

Headers, Male Pins Feature Summary

• High-density 7-row layout for maximum contact count in minimal footprint
• Thermoplastic PPS construction ensures high heat resistance during soldering
• Surface mount termination style facilitates automated PCB assembly

Headers, Male Pins Applications

• Industrial control systems requiring dense signal routing
• Telecommunications equipment with high pin-count interfaces
• Automotive electronics modules needing reliable SMT connections

Headers, Male Pins Procurement Notes

Verify that the specified part number matches the exact row count and pitch requirements for your design. Confirm compatibility with mating receptacles or cables from the same M50 series family. Ensure that the surface mount pad layout on the printed circuit board aligns with the manufacturer's recommended footprint guidelines to guarantee proper solder joint integrity and mechanical retention during operation.

Headers, Male Pins Selection Notes

Select this housing when a high pin count is required within a constrained vertical space. The 1.27mm pitch offers a balance between density and manufacturability. Consider the operating temperature range and chemical resistance provided by the PPS material if the environment involves harsh conditions. Ensure that the chosen termination method matches the available assembly capabilities of the production line.

Headers, Male Pins Part Context

This component is part of Harwin's extensive M50 series portfolio, which includes various housings, terminals, and accessories. The series is known for its reliability in demanding environments. The M50-3532042 specifically addresses the need for multi-row connectivity, offering a standardized solution for engineers designing complex electronic assemblies where space efficiency and connection reliability are critical factors.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 42-position count, 7-row arrangement, and 1.27mm pitch. Verify that alternative manufacturers offer housings with identical mounting hole dimensions and terminal cavity sizes to ensure interchangeability without redesigning the PCB footprint.
