M50-3630342

Headers, Male Pins Overview

The Harwin M50-3630342 is a male pin header connector from the ARCHER series, featuring a 1.27 mm pitch and two rows of contacts. It provides six positions in a vertical surface-mount configuration. The component utilizes brass contacts with gold plating for reliable conductivity. Rated for 1 A current and 250 V voltage, it operates within a temperature range of -40°C to +105°C. The housing is constructed from thermoplastic material compliant with UL 94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Vertical surface-mount design for compact PCB integration
• Gold-plated brass contacts ensure stable signal transmission
• Dual-row architecture supports high-density interconnects

Headers, Male Pins Applications

• Wire-to-board connections
• General electronic circuit interconnects
• Industrial control systems

Headers, Male Pins Procurement Notes

Verify the specific manufacturer part number against official datasheets to confirm contact count and orientation. Ensure compatibility with automated surface-mount assembly processes. Check for RoHS compliance documentation prior to final procurement approval.

Headers, Male Pins Selection Notes

Select this component for applications requiring vertical mounting with a 1.27 mm pitch. Confirm that the board layout accommodates the dual-row footprint. Validate thermal requirements against the specified operating temperature range during design phase.

Headers, Male Pins Part Context

This connector belongs to the Harwin ARCHER M50 family, designed for high-reliability applications. The series offers various configurations including headers, sockets, and cable assemblies. The M50-3630342 specifically addresses needs for vertical, surface-mounted interconnections with robust electrical characteristics.

Headers, Male Pins Replacement Considerations

M50-3630342R serves as a tape-and-reel variant of the same technical specification.
