M50-4800545

Headers, Male Pins Overview

The Harwin M50-4800545 is a 10-position dual in-line (DIL) socket assembly from the ARCHER M50 series. It features a 1.27 mm pitch, two rows of contacts, and gold-plated phosphor bronze terminals rated for 1 A current and 500 V voltage. Designed for vertical through-hole mounting, this unshrouded header utilizes a black thermoplastic housing.

Headers, Male Pins Feature Summary

• Vertical through-hole termination for secure PCB integration
• Gold-plated phosphor bronze contacts ensure reliable conductivity
• Unshrouded dual in-line design facilitates direct mating

Headers, Male Pins Applications

• General electronic circuit interconnections
• Industrial control system wiring
• Data collection equipment interfaces

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against the manufacturer datasheet to confirm exact pin configuration and housing variations. Ensure compatibility with mating pins regarding pitch and contact size. Cross-reference RoHS compliance status with local regulatory requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component for applications requiring vertical board-to-board or wire-to-board connections. The 1.27 mm pitch suits dense layouts. Verify that the unshrouded design aligns with mechanical constraints and that the 1 A rating meets the circuit's electrical demands.

Headers, Male Pins Part Context

This part belongs to the ARCHER M50 series, designed for high-density interconnects. The series supports various configurations including IDC and surface mount options. The M50-4800545 specifically addresses needs for robust, vertically mounted socket assemblies in compact industrial environments.

Headers, Male Pins Replacement Considerations

Consult official Harwin documentation for verified substitute part numbers within the ARCHER M50 family. Ensure any replacement maintains identical 1.27 mm pitch, 10-position count, and vertical orientation.
